To avoid injury, read and follow these safe priming practices.
DO NOT attempt to prime military cartridge cases with crimped primer
pockets until the crimp has been removed with a counter sink, a spe-
cial reamer or by swaging. Primers seated into crimped pockets are
subject to deformation which can cause misfi res and even detonation
during seating which can cause serious personal injury.
DO NOT attempt to seat primers against excessive resistance which
may cause detonation and possible serious personal injury. Check
to be certain that the case was not previously primed, that the fi red
primer was removed, that a portion of the primer cup wall might still
be in the primer pocket and that you are using the correct size primer.
DO NOT modify the priming system in any manner or attempt to use
similar parts or priming systems from other manufacturers. To do so
could result in primer detonations resulting in serious personal injury.
NEVER seat a primer into a powder charged case.
Before proceeding, mount the Lock-N-Load 50 BMG to a sturdy work
surface. Use three bolts at least 5/16” in diameter and of suffi cient
length to extend through the press base and work surface with enough
length to allow washers and nuts. Install the threaded portion of the
handle through the toggle block. Attach the handle nut and tighten
fi rmly. The handle nut must remain tight at all times to avoid damage
to the handle and toggle. To correctly position the primer catcher, snap
it onto the rear post as shown. Spent primers drop through the partially
hollow ram and into the primer catcher.
INSTALLATION
TM
INTRODUCTION WARNING HORNADY WARRANTY REGISTRATION
Please return in envelope within 20 days of purchase.
Name ___________________________________________
Address __________________________________________
City ____________________________________________
State ________________________ Zip _______________
email ___________________________________________
Item Purchased ____________________________________
Serial No. ________________________________________
Dealer Name ______________________________________
City ____________________________________________
State ________________________ Zip _______________
Send to:
Hornady Manufacturing
P.O. Box 1848 • Grand Island, NE 68802-1848
The single-stage Lock-N-Load 50 BMG is a big, strong press that
provides the experienced or beginning handloader with all the capac-
ity, strength, and leverage to reload all rifl e and pistol calibers. With
the Hornady Lock-N-Load 50 BMG press compound leverage system
and massive 1 1/2" ram, Lock-N-Load 50 BMG will form cases or
swage bullets. With an optional ram end adapter bushing, and
standard Lock-N-Load die bushing, the press can be converted to load
ammo with any standard die using 7/8-17 threads. With seven inches
between the top plate and the main press frame, Lock-N-Load 50 BMG
will easily handle the longest standard cartridge.
BEFORE RELOADING
Before using the Lock-N-Load 50 BMG press, read the instruction
manual carefully to fully learn how to safely operate the related
reloading equipment. Failure to properly operate certain reloading
equipment can result in severe personal injury and/or equipment dam-
age. If you have read these instructions and still do not understand
some operations, call us at 1-800-338-3220 and a technician will
assist you . This instruction manual contains specifi c safety and
operating information. It should be considered a permanent part of
your reloading equipment and remain with the equipment at all times
for easy reference.
SAFETY
Reloading is an enjoyable and rewarding hobby that can be conducted
safely. But, as with any hobby, carelessness or negligence can make
reloading hazardous. When reloading, safety rules must be followed.
By observing these rules, the chance of a hazardous occurrence caus-
ing personal injury or property damage is minimized.
PRODUCT WARRANTY
"We guarantee our reloading tools and accessories for life."
No Risk Lifetime Warranty:
All Hornady reloading tools and accessories are warranted against ma-
terial defects and workmanship for the life of the product. Parts, which
by nature of their function are subject to normal wear such as springs,
pins, bearings, etc. Parts which have been altered, abused, or neglected
are excluded from the warranty.
If the product is deemed defective by either workmanship or materials,
the reloading tool or accessory will either be repaired, reconditioned or
replaced at Hornady Manufacturing Company's option. If it breaks, we'll
repair it or replace it at no charge.
To return a product, call toll free, 800-338-3220 and ask for Customer
Service. They will provide instructions for return if the problem can't be
solved over the phone.
Prices and or specifi cations are subject to change without notice. For
the best prices on any of our products, contact your nearest Hornady
dealer. Hornady Manufacturing Company cannot assume liability for
damage which may result from use of the products or information
given herein, since Hornady has no control over the manner in which its
products or components are used during reloading.
GUIDELINES
General
* Use all equipment as the manufacturer recommends. Study the instructions carefully and
become thoroughly familiar with the operation of the product. If you do not have written
instructions, request a copy from the equipment manufacturer.
* Don’t take short cuts. Attempting to bypass established procedures is an invitation to
an accident.
* Observe “good housekeeping” in the reloading area. Keep tools and components neat,
clean and orderly. Promptly and completely clean up primer and powder spills.
* Reload only when you can give it your undivided attention. Do not reload when fatigued or
ill, or under the infl uence of medications or alcohol. Develop a reloading routine to avoid
mistakes which may prove hazardous. Don’t rush — load at a leisurely pace.
* Always wear adequate eye protection to protect your eyes from fl ying particles. You as-
sume unnecessary risk when reloading without wearing safety glasses.
Loading Data
* Use only laboratory-tested reloading data. We highly recommend the Hornady
reloading manuals.
Primers will explode!
* Keep away from children.
* Do not smoke near primers.
* Primers are designed to explode and will do so when subjected to heat or percussion.
* Always wear safety glasses when handling primers.
* DO NOT force primers. All primers in the near vicinity of an exploding primer will usually
also detonate violently. Do not store or handle primers in bulk.
* For identifi cation and safety, keep primers in their original protective packaging.
* An absolute minimum of primers should be kept at the loading operation. Open only one
package tray at a time.
* Do not decap live primers.
* Never attempt to seat or reset a primer in a loaded round.
Record Keeping
* Keep complete records of reloads. Apply a descriptive label to each box showing the date
produced, and the primer, powder and bullet used. Labels for this purpose are packed
with Hornady bullets.
50 Cal. BMG PARTS
1
4
2
3
.50 BMG Shell Holder
Lock-N-Load Bushing
Lock-N-Load Bushing Adapter
Ram Prime System
Your 50 Cal BMG press
comes with the
following items:
1
4
2
3
Reloading Die
(optional)
Reloading Die
(optional)
Handle Lock Nut
Primer Catcher
Toggle Block
Shell Holder
Handle
Die Station
