Overhang, Side view – Mueller 24x24 DIY KIT FOR SLAB User Manual

Page 18

background image

DETAIL X

NOTE: ROOF SHEET IS DESIGNED
TO HAVE A

2

1
2

" OVERHANG

2

1
2

"

SIDE VIEW

X

EAV

E

TR

IM

10"

12"

12"

2"

36"

UPN-PANEL

BUTYLTAPE

To avoid leaking place
sealer tape between
roof sheets only.

LAP SCREW

TEK SCREW

EA

VE

TR

IM
