Mueller, Inc. 12x15 DIY Back Yard Kit Instructions; For additional information, see the D.I.Y Installation Video
23
BACK SIDE WALL
Roof to wall sheet alignment
Align major ribs from wall to
major rib on roof
10"
Lap TEK Screw
TEK Screw
TEK Screw
TEK Screw
12"
12"
36"
NOTE: Make sure
panels remain
square during
installation.
NOTE: If optional double
door is used, roof
and wall sheets
will not align.
