Bühler – Buhler 2895E User Manual
Page 39
bühler
Allied Front-End Loader
P4493
- 37 -
895E TSL & 2895E S TSL
Main
Frame
Assembly
Item Part No.
Description
2895E TSL 2895E S TSL
1
24967
2895 TSL Main Frame Weldment (bushings incl.)
1
-
1
24945
2895 S TSL Main Frame Weldment(bushings incl.)
-
1
2
25388
2895 Euro Quick Attach Weldment
1
1
3
Ref.
Lift Cylinder (see cylinder assembly)
2
2
4
Ref.
Bucket Cylinder (see cylinder assembly)
2
2
5
117161 Pin Weldment (Quick Attach)
2
2
6
24942
Upright Weldment Right (TSL)
1
1
7
24941
Upright Weldment Left (TSL)
1
1
8
115527 Pin Weldment (Upright)
2
2
9 115473
Pivot
Plate
2
2
10
115583 Leveling Tube Weldment
2
-
10
115475 Leveling Tube Weldment
-
2
11 116344 Link
Weldment
17.0"
4
4
12
117141 Link Assembly 10.50" (113691 included)
4
4
13
116349 Link Spacer 2.0 OD x 2.5 LG.
2
2
14 115486 Stand
Tube
2
2
15 114303 Stand
Foot
2
2
16
115906 Pin 1.25 x 6.75
10
10
17
117494 Pin 1.25 x 7.00
4
4
18
115900 Pin 1.25 x 5.25
2
2
19
115908 Pin 1.50 x 6.75
2
2
20
113579 Bushing 1.50 ID x 1.88 OD
4
4
21
113633 Bushing 1.25 ID x 1.63 OD
20
20
22
113691 Bushing 1.25 ID x 1.63 OD x 0.75 LG
8
8
23 12779 Hair
Pin
Clip
6
6
24 110907 Stand
Pin
2
2
25
81669
Hex Bolt 0.625 UNC x 3.5 Lg.
2
2
26
81967
Nut Lock 0.625 UNC
6
6
27
81344
Nut Lock (Nylon) 0.375 UNC
13
13
28
81570
Flat Washer 0.375 DIA
4
4
29
24242
Cross Tube Cover
1
1
30
81592
Nut Hex 0.375 UNC GR2 PL
4
4
31
81637
Lock Washer 0.50 DIA
2
2
32
813228 Wing Nut 0.50 DIA
2
2
33 115909 Pin
Cap
18
18
34
81615
Washer Lock 0.438 DIA
18
18
35
81597
Hex Bolt 0.438 UNC x 1.00 Lg. GR5 PL
18
18
36
115564 Leveling Rod
1
1
37
81966
Nut Lock (Nylon) 0.50 UNC
2
2
38 114969 Guide
Bracket
1
1
39 115012 U-Bolt
1
1
40
116347 Pin 1.25 x 7.25
4
4
41 909277 Operator’s
Manual
Holder
1
1
42
81552
Bolt Hex 0.313 UNC x 1.25 Lg.
2
2
43
84541
Nut Lock (Nylon) 0.313 UNC
2
2
44
812623 Flat Washer 0.313 DIA
2
2
45
84583
Grease Fitting 1/8 NPT Straight
22
22
46
967488 Hex Bolt 0.375 NC x 2.75 Lg. GR5 PL
4
4
