4
Owner’s Manual
HEAT SWITCH FUNCTIONS
Functions are selected by turning rotary switch to the desired position.
-----Provides 1500 watts of heat output operation and oscillation.
-----Provides 800 watts of heat output operation
-----
Fan only operation for cooling comfort.
ELECTRICAL RATINGS
This product is rated (1500W) at 120V, 60 Hz.
OPERATION
away from any wall or combustible material.
* With the selection switch in the OFF " " position, plug the heater into a
polarized 120V outlet.
* Turn the thermostat control fully clockwise to the "MAX" setting.
* To turn the heater on, selection switch while turning it clockwise to the desired
position ( for 1500 W, or for 800 W). The power light will illuminate.
* When the room reaches a comfortable temperature, slowly turn the thermostat
thermostat setting equals the room temperature. At this setting, the thermostat
temperature.
* If using the oscillation feature, at the point your desired temperature is reached,
the heater will stop oscillating.
* Turn the selection switch to OFF " "and unplug the heater when you are
IF YOUR HEATER FAILS TO OPERATE:
* Be sure it is plugged in and that the electrical outlet is working.
Unplug the heater and wait at least ten minutes for it to cool. Carefully remove
the obstruction. Plug the heater back in and restart it as described under
OPERATION.
* If you still notice the same defect above mentioned, remove the plug from the
socket and have the appliance serviced by authorized service personnel only.
* Check that the thermostat is not set too low. With the selection switch set to a
heat setting, turn the thermostat up (clockwise) until the heater restarts.
