19
General Parts Listing
Owner’s Manual
APA P art No. P art No Description Qty.
This list is provided for reference
purposes only.
All repairs and part replacement
should be performed by a
qualified technician.
Some parts may not be
available as single replacements.
SP-GG200-A-01-JD EG-LY152-A01 Crankcase assy. 1
SP-GG200-A-02-JD EG-HT152-A02 Oil seal 2
SP-GG200-A-03-JD EG-HT152-A03 Bearing 6203 1
SP-GG200-A-04-JD EG-HT152-A04 Crankcase gasket 1
SP-GG200-A-05-JD EG-HT152-A05 Drain bolt 2
SP-GG200-A-06-JD EG-HT152-A06 Washer 2
SP-GG200-A-07-JD EG-HT152-A07 Dowel pin 2
SP-GG200-A-08-JD EG-HT152-A08 Bearing 6203 1
SP-GG200-A-09-JD EG-HT152-A09 Crankcase cover 1
SP-GG200-A-10-JD EG-HT152-A10 Oil level cap assy. 2
SP-GG200-A-11-JD EG-HT152-A11 Flange bolt 6
SP-GG200-A-12-JD EG-HT152-A12 ”O” Ring 2
FIG A. CRANKCASE ASSY
