8
Figure 5a
A = Thickness of mounting surface
Mounting
surface
Front of
fridge freezer
Drain plug
Base of fridge freezer
C
Dimensions in mm
Figure 5b
Figure 5c
Hex key
A
Mounting surface
of thickness ‘A’ mm
Rubber mounting foot
Mounting bolt
