Off Road Unlimited 70000-B Ford Trac Bar kit for 99-04 F-250, F-350, and Excursion - Manual (Page 6)

ORU- 1999-2004 Ford Super Duty & Excursion Trac Bar System
8) Support one side of the axle and remove the factory lower shock mount (which is also the
upper spring plate) and discard. Install the ORU lower spring plate/shock mount. Repeat on
opposite side of vehicle (photo 5).
Photo 5
9) With the vehicle on the ground at ride height, assemble and install new adjustable trac bar with
supplied spacers (aluminum spacers @ axle) and bolts.
10) Re-attach lower shocks with new hardware. If you do not have dual shocks, you will need to
bolt the single shock in the lower bracket mount that provides the best angle (closest to vertical).
11) Install urethane bump stops (photo 6).
Photo 6
12) Optional: Install limiting straps to center hole in lower shock plate and a suitable upper
mounting location (varies by application).
offroadunlimited.com
page 5
