B LAUPUNKT S PECIFICATIONS - VA4100, 4/3/2 C HANNEL A MPLIFIER
– 1 –
All power ratings conform to CEA-2006 standards.
PARAMETER/FEATURE VA4100
Channels 4/3/2
Size ( L x W x D) without trim panels 15.1x9.1x2.4 inches (382x231x60mm)
Weight 14.5 lbs. (6.6 kg)
Spade screw speaker terminals? YES
Maximum terminal wire size 10 ga.
Subsonic filter YES (10 Hz)
Separate front/rear or left/right gains? F/R-YES L/R-NO
Fuse Type ATC spade -Two 40A
Speaker short, short to +12V, and short to ground protection? YES
High, low, and reverse voltage protection? YES
Power output transistors Low QZ MOSFET
Power supply transistors MOSFET
Minimum speaker impedance (non-bridged) 2 ohms
(bridged) 4 ohms
PERFORMANCE DATA
Rated power output @ 0.1% THD, 14.4V (CEA-2006)
4 channels into 4 ohms / 2 ohms (watts rms) 4 x 100 W / 4 x 150 W
2 channels into 4 ohms (watts rms) 2 x 300 W
Max Dynamic Power (watts rms) 700W
Total Harmonic Distortion @ full power 0.1% THD
Signal/Noise ratio (gain controls in center)
Measured @ 1 watt / 1 kHz dBA >80
Measured @ full rated power (0.1% THD) dBA >100
Damping factor >100
Frequency response (full-range mode) 15 - 50,000 Hz
High-pass crossover frequency limits 50 H z - 250 Hz (variable), 12dB/oct
Low-pass crossover frequency limits 50 H z - 250 Hz (variable), 12dB/oct
Input impedance 10 kohms
Input signal voltage control range 0.3 - 6.0 vrms
Current Draw @ 13.8 VDC (typical values @ X watts / Efficiency %)
@ full rated power, unbridged (@ 4 ohms) 50 A (50%)
@ 33% rated power, unbridged (@ 4 ohms) 30 A (35%)
@ idle (@ 4 ohms) 1 A
Minimum battery voltage to maintain rated power 12.6 VDC
Usable battery voltage 10 - 16 VDC
Trigger line voltage range 10 - 16 VDC
Trigger line current draw < 20 mA
Turn on delay time @ 2.0 seconds
Thermal shutoff temperature (average heat-sink temp) @ 85˚ C (185˚ F)
This information is subject to change without notice! • Änderungen vorbehalten! • Sous réserve de modifications!
Modifiche riservate! • Wijzigingen voorbehouden! • Ändringar förbehålles! • Modificaciones reservadas! • Sob reserva de alterações!
