30PF9946/37
Technical specifications Product highlights
flat TV with Digital Crystal Clear
30" LCD
Date of issue 2006-07-07
Version: 4.0
12 NC: 8670 000 20573
UPC: 0 37849 94596 4
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
© 2006 Koninklijke Philips Electronics N.V.
All Rights reserved.
www.philips.com
Picture/Display
• Aspect ratio: 15:9
• Brightness: 450 cd/m²
• Contrast ratio (typical): 350:1
• Diagonal screen size: 30 inch / 76 cm
• Visible diagonal screen size: 76 cm
• Display screen type: LCD WXGA Active Matrix
TFT
• Picture enhancement: Active Control + Light
sensor, Comb Filter Digital, Digital Crystal
Clear, Progressive Scan, Widescreen Plus
• Screen enhancement: Anti ageing circuit, Anti-
Reflection coated screen
• Viewing angle (h / v): 176 / 176 degree
• Panel resolution: 1280 x 768p
• Response time (typical): 16 ms
• Smart Picture: 5 picture presets
Supported Display Resolution
• MAC 640 x 480: 66.67 Hz
• MAC 832 x 624: 74.55 Hz
• SVGA 800 x 600: 50, 60, 72, 75, 85 Hz
• VGA 640 x 350: 70, 85 Hz
• VGA 640 x 480: 60, 72, 75, 85 Hz
• VGA 720 x 400: 70, 85 Hz
• XGA 1024 x 768: 60, 70, 75, 85 Hz
Sound
• Sound Enhancement: Smart Sound
• Sound System: Virtual Dolby Surround
• Output power (RMS): 2 x 10W
• Total Sound Power (RMS): 40 W
Loudspeakers
• Built-in speakers: 2
Convenience
• Ease of Installation: Auto Volume Leveler,
Autostore, PLL Digital Tuning, Plug & Play
• Ease of Use: On Screen Display, Top Controls
• Remote control type: RC4334/01
• Picture in Picture: Picture in graphics, Twin page
text
• Remote Control: Multi-functional
• Screen Format Adjustments: 6 Widescreen
Modes, Auto Format, Auto Screen Fit, Subtitle
and Heading Shift
• RC controls Philips: Amp, DVD, Sat, VCR, TV
Tuner/Reception/Transmission
• Tuner bands: Hyperband, S-Channel, UHF, VHF
• TV system: NTSC
• Video Playback: NTSC, PAL, SECAM
• Aerial Input: 75 ohm coaxial (IEC75)
Connectivity
• Other connections: Analog audio Left/Right out,
Antenna IEC75, DVI-D
• AV 1: Audio L/R in, CVBS in
• AV 2: Audio L/R in, CVBS, S-Video Y/C
• AV 3: Audio L/R in, YPbPr
• AV 4: Audio L/R in, YPbPr
• Side: Audio L/R in, CVBS in, Headphones out, S-
Video Y/C
Power
• Power consumption: 185 (tbc) W
• Standby power consumption: < 2 W (tbc)
• Mains power: AC 96 - 140V +/- 10%
• Ambient temperature: +5 -/+ 40 C
Dimensions
• Weight incl. Packaging: 23 kg
• Color cabinet: Pearl - White Silver (11092)
• Set dimensions (W x H x D):
895 x 490 x 110 mm
• Set weight: 18 kg
Accessories
• Included Accessories: Table top stand, Wall
mounting bracket
• Optional accessories: Floor stand, Table top
stand
•
Digital Crystal Clear
Digital Crystal Clear is a package of picture innovations
that digitally adjusts and optimizes picture quality to
optimal contrast, color and sharpness levels. It's like
watching vivid cinema-like images.
3D Combfilter
The 3D comb filter separates brightness and color
signals better in 3D domain to eliminate cross-color,
cross-luminance and dot-crawl distortion - all of which
detract from your viewing pleasure. The 3D digital
comb filter performs field-by-field comparisons of the
television image to accurately separate the color from
the black-and-white information and remove both
horizontally and vertically hanging dots, as well as dot
crawl. The result is a razor sharp image.
Active Control + Light Sensor
Active Control is a unique and intelligent way of
optimizing picture quality by measuring and analyzing
the incoming signal to automatically adjust picture
quality settings. Active Control with Light Sensor uses a
sensor to adjust the picture brightness depending on the
room light conditions.
Virtual Dolby Surround
Virtual Dolby Surround is a processing technology for
enhancing surround sound effects. It which create the
sensation of Dolby Pro Logic without the necessity of
additional rear speakers. You become totally immersed
in your television experience.
New Arch Design
