Blue Rhino WAD1091W - Manual (Page 3)

Contact 1.800.762.1142 for assistance. Do not return to place of purchase.
page no.
3
Parts List
1 Handle 58-11-001
2 Spark Guard 58-11-002
3 Handle Nut* 58-11-003
4 Wood Grate 58-11-004
5 Bowl 58-11-005
6 Bowl Support 58-11-006
7 Leg A 58-11-007
8 Leg B 58-11-009
9 Fireplace Tool 58-11-010
* Pre-assembled
Hardware
A
Screw M5x10 Nickel Plated 4 pcs
B
Screw M5x25 Nickel Plated 1 pc
Exploded View
1
2
3
4
5
7
Tools Required for Assembly (Not Included)
#2 Phillips Head Screwdriver 1 pc
6
8
9
