BookEndz ® dOcK feATUres & POrTs
Rear View
Plug all of your peripherals into the ports shown below on the
rear of your BookEndz Dock. Be sure all peripherals are turned
off prior to connecting them to your BookEndz Dock.
1. USB 2.0 6. RCA Audio Out-Right
2. Firewire 400 7. RCA Audio Out-Left
3. Ethernet 8. USB 2.0
4. DVI* 9. Audio Line In
5. VGA Monitor* 10. Headphone Out
* The BookEndz Dock splits the DVI Port of the MacBook Pro into a DVI and
VGA Monitor Port. (Cannot be used at the same time.)
