Philips 17E4222E82 User Manual
En introduction, Feature highlights
1
E
N
Introduction
The 107E colour monitor displays sharp images of text and graphics
with a maximum resolution up to 1280x1024 pixels. It is optimal for
Windows, CAD / CAM / CAE, desktop publishing, spread sheets, multi-
media, and any other application which demands large screen size and
high resolutions.
This monitor automatically scans horizontal frequencies from 30KHz to
70KHz, and vertical frequencies from 50Hz to 130Hz. With
microprocessor based digital controlled circuit, the monitor can
automatically adjust itself to the video card’s scanning frequency and
displays an image with precise parameters you desire. The wide range
of scanning frequency supports variety of operating platforms, such as
IBM PC and compatibles.
Feature Highlights
•
On-Screen-Display function provides more informations when the
user operates the control functions. This feature provides user-
friendliness and ease-of-use when operating the monitor.
•
Anti-Glare and Anti-Static screen coating eliminate any bad effects
caused by the screen surface such as reflection of the room lights
and dust attraction.
•
Green Design including automatic power saving function (NUTEK)
and low emission MPRII compliance shows our commitment in
environmental care.
•
DDC1/DDC2B allows communication between the monitor and PC
system for optimal video configuration.
