8 EN
5 Other features
Synchronize the iPod/iPhone
with a PC
1
Insert the iPod/iPhone into the dock.
2
Connect the active speaker to your PC
through the supplied USB cable.
3
Press on the active speaker.
» The LED indicator flashes.
4
Start iTunes to snychronize your docked
iPod/iPhone with the PC.
Note
•
Make sure that you have not disabled automatic
synchronization in iTunes. Otherwise , start
synchronization from iTunes manually.
To exit synchronization mode:
1
Eject your iPod/iPhone from iTunes .
2
Press on the active speaker.
» The speakers return to audio mode .
6 Product
information
Note
• Product information is subject to change without prior notice.
Specifications
Amplifier
Rated Output Power 2 x 10 W RMS
Frequency Response 60-20000 Hz, ±3dB
Signal to Noise Ratio > 77 dB
MP3 Link
600 mV RMS 22 kohm
Speakers
Speaker Impedance 4 ohm
Speaker Driver 2.5 inch full range + dia
60mm x 2 Woox
General information
AC power Model: AS360-120-
AQ300
Input: 100-240 V~, 50/60
Hz 1.2 A
Output: 12.0 V 3A
Operation Power
Consumption 10 W
Standby Power
consumption <0.5 W
Dimensions
- Main Unit
(diameter x height) W148*D148*H150mm
Weight
- With Packing
- Main Unit
3.1 kg
0.8 kg
