Briggs & Stratton 030211-1 - Manual (Page 3)

6200W Portable Generator
3
EXPLODED VIEW - PARTS LIST
Item Part # Description
1 M197464GS CRADLE (Includes Items 20, 31 &
55)
2 194150GS KIT, Vibration Mount
3 * NUT, M8 Flange Serrated
4 190220GS HOUSING, Engine Adapter
5 * NUT, Hex, M8-1.25
6 NSP ASSY, Alternator (see page 4)
7 * TPHMS, M8 - 1.25 x 35
8 96796GS WASHER, 8.4 x 22.2 x 3
9 * WASHER, Lock M8
10 190274DGS SBHCS, 3/8-16 x 7/8
11 187365FGS HHCS, 5/16-24 x 7.44
12 * HHCS, M8 1.25 x 25
14 189009GS BRACKET, Muffler
15 695398 GASKET, Exhaust
16 * HHCS, M6-1.0 x 12
17 189008GS MUFFLER
18 * SHCS, 5/16 - 18 x 7/8"
19 83083GS SCREEN, Spark Arrest
20 B4986GS DECAL, Ground
21 194153GS KIT, Vibration, Mount
22 86494GS SCREW, Wing M6 - 1.0 x 16
24 194390GS SHIELD, Heat
25 191190GS CAP
26 74908GS TAPTITE, M5-0.8 x 10
27 B193200GS ASSY, Handle/Grip
28 198669GS GRIP
29 * HHCS, 1/4-20 x 3/4
30 * WASHER, Shakeproof, Ext #10
31 196830GS DECAL, Hot Muffler
32 * NUT, 1/4 – 20
33 * NUT, 5/16-24
34 195422GS COVER, RBC w/Cap
35 791745 KIT, Fuel Hose (cut to fit)
36 * WASHER, Lock, 1/4
37 B2153GS SCREW, 12-14 x 7/8 Self Drilling
38 56893GS SCREW, 10-24 x 1/2 Crimptite
39 188987GS PLATE, Mounting Switch
40 195477GS KIT, Hardware Tank Fuel (Includes
Qty 4)
41 192980GS KIT, Valve, Tank
Item Part # Description
43 77282GS SWITCH, Starter
44 194217GS ASSY., Tank, Fuel (Includes Items
41, 50, 51, 52 & 56)
45 B4363GS CAP, Fuel Gauge
46 B4135GS PIN
47 77395GS NUT, M6 Flange Lock
48 195373GS WIRE, Ground
49 * WASHER, M6 Shakeproof
50 188333GS DECAL, Instruction, Fuel Level
51 194799GS DECAL, Danger
52 189235GS DECAL, Start Instructions
53 194034GS KIT, Handle Fold-down Hardware
54 194448GS KIT, Insulation with Clip
55 197798GS DECAL, Fuel Shut-off
56 202997GS DECAL, CO Warning
58 191757GS ASSY, Control Panel
59 * NUT, Palnut, 3/16"
60 194389GS SHIELD, Heat
68 195680GS TRAY, Battery
69 193043GS BATTERY
70 * HHCS, M6 - 1.0 x 12
71 192531GS ASM, Jack, DC
73 58359GS LUG, 5/16 #22/18 I-S
74 193347GS KIT, Battery Hardware
76 185939KGS WIRE ASM, #55
78 189302CGS WIRE ASM, #13
81 189302GGS WIRE ASM, #16
900 § ENGINE
Parts Not Illustrated
MS3430 MANUAL, Engine, B&S
195529GS MANUAL, Operator’s
BB3061GS BOTTLE, Oil
B4177GS CHARGER, Battery
202180GS DECAL, Family, CA EVP
195578GS KIT, Decals Service
* - Items without part numbers are common fasteners and
are available at your local hardware store.
§ - Contact Engine Manufacturer
