The label on your tool may include the following symbols.
V ..........................volts
A..........................amperes
Hz ........................hertz
W ........................watts
min ........................minutes
......................alternating
current
......................direct current
no ........................no load speed
..........................Class II Construction
........................earthing terminal
........................safety alert symbol
.../min ..................revolutions or
reciprocations
per minute
bpm.....................beats per minute
Extension Cords
When using an extension cord, be sure to use one heavy enough to carry the current your
product will draw. An undersized cord will cause a drop in line voltage resulting in loss of
power and overheating. The following table shows the correct size to use depending on
cord length and nameplate ampere rating. If in doubt, use the next heavier gage. The
smaller the gage number, the heavier the cord.
4
FS6000FD
FUNCTIONAL
DESCRIPTION
1. Variable speed switch
2. Lock-on button
3. Forward/reverse slider
4. Two-gear selector
5. Drilling mode selector
6. Chuck
7. Chuck key
8. Depth stop
9. Side handle
10. Belt clip
11. Fast drive remov. chuck
12. Bit storage
2
3
1
2
3
1
2
3
1
2
3
1
6
11
6
6
9
5
10
9
12
5
FS6500HD
FS7000D
FS8000HD
9
8
7
12
4
10
Minimum Gage for Cord Sets
Volts
Total Length of Cord in Feet
120V
0-25 26-50 51-100 101-150
240V
0-50
51-100 101-200
201-300
Ampere Rating
More
Not more
American Wire Gage
Than
Than
0
-
6
18
16
16
14
6
-
10
18
16
14
12
10 -
12
16
16
14
12
12 -
16
14
12
Not Recommended
