4
2. Setting up the monitor
2. Setting up the monitor
2.1 Installation
Package contents
220S4LS/220S4LA
220S4L
220S4LC
220S4LC
Install the base
220S4LS/220S4LA
1. Place the monitor face down on a smooth
surface. Pay attention not to scratch or
damage the screen.
2. Hold the base with both hands.
(1) Gently attach the base to the column
until the three guiding pins rest into the
position holes.
8VH \RXU ÀQJHUV WR WLJKWHQ WKH VFUHZ
located at the bottom of the base, and
secure the base to the column tightly.
1
2
VGA (Optional) Audio (Optional) DVI (Optional)
Audio (Optional) VGA (Optional) DVI (Optional)
