MITSUBISHI DIESEL ENGINES S16R-Y2PTAW-1 - Manual (Page 3)

Certified for US EPA-Tier 2 / Constant Speed
Standard Model [1600kWe/60Hz]
MITSUBISHI
S16R-Y2PTAW-1 SPECIFICATION SHEET DIESEL ENGINES
ENGINE RATING
All data represent net performance with standard accessories such as air cleaner, inlet /exhaust manifolds, fuel oil system,
L.O. pump, etc. under the condition of 100kPa(29.6inHg) barometric pressure, 77
o
F(25
o
C) ambient temperature and 30%
relative humidity.
ITEM UNIT STAND-BY POWER PRIME POWER
60Hz 60Hz
Engine Speed rpm 1800 1800
No. of Cylinders
Bore mm
(in.)
Stroke mm
(in.)
Displacement liter
(in. 3 )
Brake Horse power without Fan HP 2346 2133
(kW) (1750) (1591)
Brake Mean Effective Pressure kgf/cm 2 18.2 16.5
without Fan (psi) (259) (235)
Mean Piston Speed m/s 10.8 10.8
(ft/min) (2126) (2126)
Maximum Regenerative Power HP 258 258
Absorption Capacity without Fan (kW) (192) (192)
Intake Air flow m 3 /min 168 151
(CFM) (5932) (5332)
Exhaust Gas Flow m 3 /min 443 399
(CFM) (15642) (14089)
Coolant Flow liter/min 1850 1850
(U.S. GPM) (489) (489)
Coolant Flow to Intercooler liter/min 920 920
(PTAW only) (U.S. GPM) (243) (243)
Cooling Air Flow m
3
/min
(Std. Fan) (CFM)
Allowable Fan Loss Horse Power HP 67 67
(kW) (50) (50)
Radiated Heat to Ambient kcal/hr 126194 113619
(BTU/min) (8346) (7515)
Heat Rejection to Coolant kcal/hr 546842 492350
(BTU/min) (36167) (32563)
Heat Rejection to Air Cooler kcal/hr
(PTAW Version) (BTU/min) (36167) (32563)
Heat Rejection to Exhaust kcal/hr 1481893 1320996
(BTU/min) (98010) (87369)
Noise Level (1 m height & distance) dB(A) 112 109
(excludes, lntake,Exhaust & Fan)
The specifications are subject to change without notice.
APPLICATION : GENERATOR
Pub. No. T13-0635-E
Oct. '06 Printed in Japan
(3989)
16
170
(6.69)
180
(7.09)
65.37
