17
6.3 Delete an entry in the Call List
1. Follow Steps 1 and 2 in Section 6.1.
2. Press DELETE.
3. Press to confirm.
6.4 Delete
1. Follow Steps 1 and 2 in Section 6.1
. 2. Press DELETE ALL.
3. Press to display CONFIRM?.
4. Press to confirm. All entries will be deleted and the display will show
EMPTY.
7 PHONE SETTINGS
Your phone comes with a selection of settings that you can change to
personalise your phone the way you like it to work.
7.1 Date and Time Settings
If you subscribe to Caller Display the time and date settings will be automatically
updated by the
The Caller Display service only sends the month and date, not the year, so you
may need to set the year.
7.1.1 Change the Date Format
1. Press
HS SETTINGS.
2. Press and to select DATE & TIME.
3. Press and to select DATE FORMAT.
18
4. Press and to select your desired date format
(DD-MM-YYor MM-DD-YY).
5. Press to confirm.
7.1.2 Change the Time Format
1. Press
HS SETTINGS.
2. Press and to select DATE & TIME.
3. Press and to select TIME FORMAT.
4. Press and to select your desired time format
5. Press to confirm.
7.1.3 Set the Time
1. Press HS SETTINGS.
2. Press and to select DATE & TIME.
3. Press and to select SET TIME.
4. Press and then enter the time information in 24 hour format.
5. Press to confirm.
Note: If time has been set before, the current time will display, otherwise,
“HH:MM” will display.
7.1.4 Set the Date
1. Press
HS SETTINGS.
2. Press and to select DATE & TIME.
3. Press and to select SET DATE.
4. Press and then enter the date information. The date entered will be in
5. Press to confirm.
Note: If date has been set before, the current date will display, otherwise,
the format you set in Section 7.1.1.
“DD-MM-YY ” will display.
7.2 Alarm Settings
You can set an alarm time on the handset. When an alarm is set, the
Icon> is shown on the handset display.
and “ALARM ON ” flash on the handset display, and the alarm
tone rings for 45 seconds. You can press any key to disable the alarm. If the
snooze function is activated, the alarm will sound again at the end of the snooze
period of seven minutes. You can also press and hold while the
Note:
a. A key press will still disable the alarm even if the handset keypad is locked
b. The alarm volume level is the same as the settings of the handset ringer
volume. If the handset ringer is set to VOLUME OFF, the alarm still sounds
at VOLUME 1 level.
when the alarm rings.
( 12 HR or 24 HR).
19
c. During an external call or internal call, if an alarm is set and when the alarm
time is reached, the and “ALARM ON” will still flash. An
alarm tone will be emitted from the earpiece to alert the user the alarm time
is reached. Once the user presses any key or presses and holds
d. During paging or ringing, the alarm will not sound when the alarm time is
reached. However, if the snooze function is enabled and there is no paging
7.2.1 Turn on/off the Alarm
1. Press
HS SETTINGS.
2. Press and to select ALARM.
4. Press to confirm.
Note: If ON is selected, you will be asked to set the alarm time.
7.2.2 Set the Alarm Time (If Alarm time is set to be ON)
1. Follow Steps 1 to 4 in Section 7.2.1. 2. Enter the alarm time in 24 hour format.
3. Press to display "SNOOZE".
4. Press and to select snooze ON or OFF.
5. Press to confirm.
7.3 Handset
Settings
7.3.1 Set the Ringer Melody for Internal Calls
1. Press HS SETTINGS.
2. Press and to select RING SETUP
3. Press and to select INT RING.
4. Press and to select the melody you want to hear for
Note: The respective melody will be played while browsing the ringtone list.
5. Press to confirm.
3. Press and to select ON/OFF.
to disable the alarm, the display will revert to the call duration.
or ringing, the alarm will sound again at the end of the snoo .
internal calls.
7.3.2 Set the Ringer Melody for External Calls
1. Press
HS SETTINGS.
2. Press and to select RING SETUP.
3. Press and to select EXT RING.
4. Press and to select the melody you want to hear for
Note: The respective melody will be played while browsing the ringtone list.
5. Press to confirm.
7.3.3 Set the Ringer Volume
1. Press
HS SETTINGS.
2. Press and to select RING SETUP.
3. Press and to select RING VOLUME.
4. Press and to select the desired ringer volume (a total of
6 ringer volume levels including VOLUME OFF).
Note: The respective ringer volume will be played during your selection.
If VOLUME OFF is selected, the icon will be displayed.
5. Press to confirm.
7.3.4 Set Alert Tones
Three different alert tones are set on by default, but can be turned off, if desired.
Key Tone - a single beep is emitted when you press a key.
you need to charge the handset batteries.
1. Press HS SETTINGS.
2. Press and to select TONE SETUP.
3. Press and to select KEY TONE / BATTERY TONE /
4. Press and to turn on or off these tones.
5. Press to confirm.
Out of Range Tone - emitted while you are talking on the phone to alert you to
move loser to the base unit, before the call is lost.
Low Battery Tone - emitted while you are talking on the phone to alert you that
OUT OF RANGE.
7.3.5 Set the Handset Language
1. Press
HS SETTINGS.
2. Press and to select LANGUAGE.
3. Press and to select the desired language.
4. Press to confirm.
7.3.6 Rename the Handset
1. Press HS SETTINGS
2. Press and to select RENAME HS.
3. Press and change the name of your handset, using to delete
4. Press to confirm.
letters and the alphanumeric keys to enter up to 10 letters for the name.
7.3.7 Choose the Information to be Displayed in Idle
You can choose to display the time or handset name in your idle screen.
1. Press HS SETTINGS.
2. Press and to select HS DISPLAY.
3. Press and to select HANDSET NAME or TIME.
4. Press to confirm.
7.3.8 Set the Auto Answer
If you turn on the Auto Answer, you can answer a call automatically by just lifting
1. Press HS SETTINGS.
2. Press and to select AUTO ANSWER.
3. Press and to turn on or off the auto answer feature.
4. Press to confirm.
the handset off the base or charger, without having to press any key.
21 20
7.4 Base Settings
7.4.1 De-register a Handset
This operation should only be necessary if one of your handsets becomes faulty
or lost and needs to be replaced.
You will need to enter the 4-digit System PIN (Default PIN is 0000) in order to
Note: You cannot de-register the handset that you are currently using.
1. Press BS SETTINGS.
2. Press and to select DELETE HS.
3. Press and the display shows "PIN?----".
the antenna icon flashing and "REGISTER" on the display.
de-register a handset from the base station.A de-registered handset will have
22
4. Enter the 4-digit system PIN.
5. Press and the first handset number is displayed.
6. Press to scroll through the list of registered handsets and
7. Press to confirm, and the chosen handset will be de-registered.
select the number of the handset you want to de-register.
network when you receive an incoming call.
7.4.2 Change the dial mode
1. Press BS SETTINGS
2. Press and to select DIAL MODE.
3. Press and to select TONE or PULSE
(The current setting is indicated by an asterisk to the right).
4. Press to confirm.
You should normally leave the dialling mode at its default setting of TONE (also
called DTMF) unless the phone is connected to an old exchange that only
Note: If PULSE dialling is set, you can press the * key to switch to TONE dialling
recognises PULSE dialling.
for the rest of that call.
7.4.3 Change the Flash (Recall) Time
1. Press BS SETTINGS.
2. Press and to select FLASH TIME.
3. Press and to select your desired flash time ( SHORT,
4. Press to confirm.
You may need to change the recall (flash) time if your phone is connected to a
PBX. The recall time options are SHORT (the default value of 100ms), MEDIUM
( 0ms) or LONG (600ms).
MEDIUM,
7.4.4 Change the System PIN Code
A 4-digit system PIN code is used for changing the system settings of the base
station. It is used to protect your phone against unauthorised use. The default
system PIN code is 0000.
1. Press
BS SETTINGS.
2. Press and to select CHANGE PIN.
3. Press and you are requested to enter the 4-digit system PIN.
4. Enter the old system PIN.
5. Press and enter the new system PIN.
6. Press and enter the new system PIN again.
Note: If the new PIN entered in Step 6 is not the same as the new system PIN
entered in Step 5, you must enter the new system PIN at step 5 again.
7. Press to confirm
7.5 Registration
already registered to your base, so you do not need to register them.
You can register additional handsets to have up to five handsets per base unit,
with each handset's number (1 to 5) shown on its display. (Note: each handset
1. Press and hold on the base station for more than five seconds, to
put the base station into registration mode. (Note: there is no feedback to
To register a new handset to your base:
2. Press REGISTRATION.
3. Press and you are requested to enter the 4-digit system PIN.
4. Enter the 4-digit system PIN.
5. Press to confirm, and the display will show SEARCHING.
If the handset registration is successful, you will hear a confirmation tone and the
will stop flashing. This may take a short while
The handset will automatically be allocated the next available handset number.
This handset number is shown in the handset display in standby mode. If the
handset registration is unsuccessful, the will still flash and the
7.6 Reset Your Phone
You can reset your phone to the default settings . After a reset, all your personal
settings, call list entries and redial list entries, will
1. Press
2. Press and you are requested to enter the 4-digit system PIN.
3. Enter the 4-digit system PIN.
4. Press to display CONFIRM?
5. Press to confirm, and the phone will be reset to its default settings.
23 24
can only be registered to one base.)
minute, so the following handset sequence must be completed within this
unchanged.
DECLARATION OF CONFORMITY
25
9
26
UK (BTP) Ver 1, 2 0
27
Problem Causes Solutions
No dialling tone when
pressing
a.The connection cord of
the base station is not
plugged in.
b.The adapter cord is not
plugged in correctly in the base station.
c. Another handset is using
the base to make a call.
d. Wrong telephone line cord
a.Check the connections. Unplug and plug back in the mains.
Check that the telephone cord
has been plugged into the base
station and the phone socket.
b.Check the base station plug and
the 230V plug (remove and plug-in).
c.Wait until the line is unoccupied. d.Use the original telephone line
cord supplied
When connect to a PBX,
no and/or wrong connection after dialling.
Dialling prefix is needed. Insert the dialling prefix
"SEARCHING" is displayed. a. Base station out of range.
b. Base station not connected to mains.
Reduce the range.
Connect base station to
mains.
The call does not work. Service not activated or
wrong setting Check your Subscription with
network or change the dial mode.
No display. Empty battery Recharge battery
key
8 TROUBLESHOOTING
Technical Support
If the fault persists...
Disconnect all other instruments connected to the same line as the
Disconnect the base unit from the telephone line and plug a different phone into
the master telephone socket.
Try making a call. If this works, the line is OK.
If the cal l does not work, and you are using a two-way socket adapter, remove
it and plug a telephone directly into the socket. If the cal l now works, the adapter
may be faulty.
This telephone is not equipped with a grounding function
used in PBX systems.
a nd try to ma ke a call.
all Call list entries
alarm is sounding, to stop the alarm and turn off the snooze function.
ze period
c
30
LONG, with the current setting indicated by and asterisk to the
right).
IMPORTANT: When you purchase a
Handset registration is only necessary when you buy extra handsets or if a
handset has become faulty.
remains
, and therefore some of
the functions may be limited when
10
We the manufacturer / Importer : Binatone Telecom Plc,1 Apsley Way London, NW2 7HF
Declare under our sole responsibility that the following product
Type of equipment: Digital cordless telephone
Model Name:
Country of Origin:
China
Brand:
complies with the essential protection requirements of R&TTE Directive 1999/5/EC on
the approximation of the laws of the Member States relating to Radio Spectrum Matters,
the Council Directive 2004/108/EC on the approximation of the laws of the Member
Statesrelating to electromagnetic compatibility (EMC) and the European Community
Directive 2006/95/EC relating to Electrical Safety.
Assessment of compliance of the product with the requirements relating to the
essential requirements according to Article 3 R&TTE was based on Annex III of the
Directive 1999/5/EC and the following standard:
Manufacturer / Importer
(signature of authorized person)
Date Signature
Binatone
The conformity to the requirements is validated by the symbol.
NOTE: In compliance with Directive 2002/96/EC, when you purchase a product
that comes with the symbol shown on the right, you are required to dispose of
electrical and electronic equipment by separate waste collection and you
cannot dispose of the product as normal waste.
This equipment and all its components, subsystems and consumable materials
formed an integral part of this product and when you decide to dispose
take them to a local recycling centre for
appropriate waste disposal, in compliance with the current regulations.
Details about the location of these centres can be obtained from
your local authority.
of them you have to
Notes for battery disposal Your product contains batteries covered by the European Directive 2006/66/EC,
which cannot be disposed of with normal household waste.
Please the local rules on separate collection of batteries. The
correct disposal of batteries helps protect the environment and prevent health
31 May 2010
be aware of
hazards.
system, all handsets are
Radio Spectrum:
EMC:
Electrical Safety: EN 60950-1: 2006+A11: 2009.
When the alarm time is reached, the
.
display will return to "REGISTER", so you will need to repeat the registration
process.
know it is in registration mode.) It will stay in registration mode for about 1
time.
be deleted but your phonebook
The
purchase shown on your sales receipt. This guarantee does not cover any
faults or defects caused by accidents,misuse, fair wear and tear, neglect,
faults on the telephone line, lightning, tampering with the equipment, or any
attempt at adjustment or repair other than through approved agents.
Please keep your sales (till) receipt this is your guarantee.
You should also keep the original packaging material.
In the unlikely event that you need to return your
While the unit is under Guarantee
1. Disconnect the base unit from the telephone line and the mains electricity
supply.
2. Pack up all parts of your
3. Return the unit to the shop where you bought it, making sure you take your sales receipt.
After the Guarantee has expired
Remember to include the mains adapter.
3. Call Helpline on 0845 345 9677 (for UK only) and ask for a quotation of the
repair charge and details of where to send your
for repair.
4. Make sure you include with your
5. Return your
If the unit is no longer under Guarantee, first follow steps 1 and 2 as for repair
under Guarantee. Then...
¾ Your name and address
¾ A cheque or postal order for the value of the repair
* This does not affect your statutory rights.
Department.
packaging.
GUARANTEE AND SERVICE
to our Repair Centre while it is under guarantee, there may be handling charge.
¾ A brief description of the fault
phone system is guaranteed for 12 months from the date of
phone system , using the original
phone system to the address given by the Service
phone system.
phone system
phone system
10
Solas 1505 Series
Solas series
Solas 150
external calls.
ETSI EN 301406: V2.1.1 (2009-07);
ETSI EN 301489-6: V1.3.1 (2008-08);
ETSI EN 301489-1: V1.8.1 (2008-04);
5
