Introduction
The PHILIPS 105S colour monitor displays sharp and brilliant images
of text and graphics with a maximum resolution up to 1024x768 pixels.
It is optimal for Windows, spread sheets, and any other application.
This monitor automatically scans horizontal frequencies from 30KHz to
54KHz, and ver tical frequencies from 50Hz to 110Hz. With
microprocessor based digital controlled circuit, the monitor can
automatically adjust itself to the video card’s scanning frequency and
displays an image with precise parameters you desire. The wide range
of scanning frequency supports variety of operating platforms, such as
IBM PC and compatibles, including Intel based platforms such as 386,
486, Pentium and Pentium Pro.
Feature Highlights
• New Styling demonstrates a smart image.
• Digital Control feature provides user-friendliness and ease-of-use
when operating the monitor.
• Anti-Glare and Anti-Static screen coating eliminate any bad effects
caused by the screen surface such as reflection of the room lights
and dust attraction.
• 85Hz refresh rate:
The maximum display resolution is 1024 x 768 pixels non-interlaced
mode. The recommanded optimum resolution up to 800 x 600 pixels
non-interlaced by maximum 85Hz refresh rate.
• Green Design including automatic power saving function (NUTEK)
and low emission MPRII compliance shows our commitment in
environmental care.
• DDC1/DDC2B allows communication between the monitor and PC
system for optimal video configuration.
