Highlights, Specifications – Philips 190EL1SB-00 User Manual
Page 2
Issue date 2014-03-14
Version: 1.0.2
12 NC: 8670 000 61408
EAN: 87 12581 53373 1
© 2014 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
Highlights
190EL1SB/00
LED Monitor
19''w (48.3 cm) E-line 1440x900 HD+
Specifications
High definition monitor
A high definition monitor is a display device designed
to deliver the exceptional picture quality of high
definition pictures, one fully prepared for HD
sources like HD set top boxes. A HD monitor offers
picture quality beyond that of progressive scan,
conforming to strict standards for HD screens that
display high resolution, top picture quality signals
through a universal connection for either analog
VGA or uncompressed DVI digital connections and
supports HDCP. It displays 720p (1280x720p @ 50
and 60 Hz progressive) and 1080i (1920x1080i @ 50
and 60 Hz interlaced) signals.
LED technology
White LED's are solid state devices which light up to
full, consistent brightness faster saving startup time.
LED's are free from mercury content which allows
for eco-friendly recycling and disposal process. LED's
allow for better dimming control of LCD backlight,
resulting in super high contrast ratio. It also gives
superior color reproduction thanks to consistent
brightness across the screen.
SmartContrast ratio 1000000:1
You want the LCD flat display with the highest
contrast and most vibrant images. Philips advanced
video processing combined with unique extreme
dimming and backlight boosting technology results in
vibrant images. SmartContrast will increase the
contrast with excellent blacklevel and accurate
rendition of dark shades and colors. It gives a bright,
lifelike picture with high contrast and vibrant colors.
5ms on/off response time
On-Off response time is the period required for a
liquid crystal cell to go from active (black) to inactive
(white) and back to active (black) again. It is
measured in milliseconds. Faster is better: Lower
response time means faster transitions and,
therefore, results in fewer visible image artifacts in
the display of transition of texts and graphics. On-Off
response time is a more important measure in the
display of business content like documents, graphs
and photos.
Mercury Free
Philips monitors with LED backlighting are free of
Mercury content, one of the most toxic natural
substances which affects humans and animals. This
allows for a eco-friendly display through out its life-
cycle from manufacturing to disposal.
Energy Star 5.0
Energy Star is a US EPA sponsored energy efficiency
program also adopted by many other countries.
Energy Star certification ensures that you are buying
a product which meets the latest power efficiency
standards which operates with maximum power
efficiency at all operational levels. New Philips
monitors are certified for Energy Star 5.0
specifications and meet or exceed the standard. For
example, in sleep mode Energy Star 5.0 requires less
than 1watt power consumption, whereas Philips
monitors consume less than 0.5watts. Further details
can be obtained from www.energystar.gov
Dual input
Dual input provides connectors to accommodate
input of both analog VGA and digital DVI signals.
Easy picture format control
Philips easy picture format control on OSD is to
switch from the 4:3 aspect ratio to the widescreen
mode and back again to match the display's aspect
ratio with your content for working with wide
documents without scrolling or viewing widescreen
media in the widescreen mode and distortion-free,
native mode display of 4:3 ratio content.
1,000,000:1
SmartContrast
Picture/Display
• LCD panel type: TFT-LCD
• Backlight type: W-LED system
• Panel Size: 19 inch / 48.3 cm
• Aspect ratio: 16:10
• Optimum resolution: 1440 x 900 @ 60 Hz
• Response time (typical): 5 ms
• Brightness: 250 cd/m²
• SmartContrast: 1,000,000:1
• Pixel pitch: 0.285 x 0.285 mm
• Viewing angle: 176º (H) / 170º (V), @ C/R > 5
• Display colors: 16.7 M
• Scanning Frequency: 30 -83 kHz (H) / 56 -75 Hz (V)
• sRGB
Connectivity
• Signal Input: VGA (Analog ), DVI-D (digital, HDCP)
• Sync Input: Separate Sync, Sync on Green
Convenience
• User convenience: Brightness, Menu, Auto, Power
On/Off
• OSD Languages: English, French, German, Spanish,
Italian, Russian, Simplified Chinese, Portuguese,
Turkish
• Other convenience: VESA mount (100x100mm),
Kensington lock
• Plug & Play Compatibility: DDC/CI, Mac OS X,
Windows 7/Vista/XP/2000/98, sRGB
Stand
• Tilt: -5/20 degree
Power
• On mode: <11.3W (EnergyStar 5.0 test method)
• Standby mode: <0.8W
• Off mode: < 0.5 W
• Power LED indicator: Operation - green, Stand by/
sleep - Amber
• Power supply: Built-in, 100-240VAC, 50/60Hz
Dimensions
• Product with stand (mm): 297 x 445 x 64 mm
• Product without stand (mm): 360 x 518 x 140 mm
• Packaging in mm (WxHxD): 358 x 445 x 180 mm
Weight
• Product with stand (kg): 3.3 kg
• Product without stand (kg): 4.9 kg
• Product with packaging (kg): 3.5 kg
Operating conditions
• Temperature range (operation): 0°C to 40°C °C
• Temperature Range (storage): -20°C to 60°C °C
• Relative humidity: 20%-80 %
• MTBF: 50,000 hour(s)
Sustainability
• Environmental and energy: EPEAT Silver, RoHS,
EnergyStar 5.0
Compliance and standards
• Regulatory Approvals: CE Mark, FCC, Class B,
SEMKO, UL/cUL
Cabinet
• Color: Black
• Finish: Glossy
•
