Product Information
Switch Off
OFF
-
-
< 0.8 W
Off
Physical Specifications
Tilt
-5°+2/-0 ~+ 20°+3/-0
Power supply
100 ~ 240 VAC, 50/60 Hz
Power consumption
45W* (typ.)
Temperature
0° C to 40° C (operating)
-20° C to 60° C (storage)
Relative humidity
20% to 80%
System MTBF
50K hours (CCFL 40K hours)
* This data is subject to change without notice.
The native resolution of the monitor is 1680 x 1050. By default, your monitor has 100% brightness (max.), 50% contrast,
and 6500K color temperature, with a full white pattern.
Pin Assignment
1.The digital only connector contains 24 signal contacts organized in three rows of eight contacts. Signal pin assignments
are listed in the following table:
Pin
No. Signal Assignment
Pin
No. Signal Assignment
Pin
No.
Signal Assignment
1
T.M.D.S. Data2-
9
T.M.D.S. Data1-
17 T.M.D.S. Data0-
2
T.M.D.S. Data2+
10
T.M.D.S. Data1+
18 T.M.D.S. Data0+
3
T.M.D.S. Data2/4 Shield
11
T.M.D.S. Data1/3 Shield
19 T.M.D.S. Data0/5 Shield
4
No connect
12
No connect
20 No connect
