Philips AJL308-37B User Manual

Clock radio

background image

Clock Radio

AJ3540

VI. Using USB device or SD/MMC

To listen to music or view photo or video, you need
to connect a USB device and/or memory card to
AJL308.

1. Plug a compatible USB device and/or memory

card (SD or MMC card) to USB port and/or card
slot of AJL308.
➜The folder(s) indicating the inserted device(s)
appears.

2. Press

3 4 to select the folder of USB device (if

present) or memory card (if present).

3. Press OK to open the folder.

The set will auto switch to clock mode.

• To switch to music mode, press MUSIC.
• To switch to photo mode, press PHOTO/

VIDEO.

• To switch to video mode, press PHOTO/

VIDEO.

4. Select the file you want to play.
5. Press OK to play.

Helpful hint:
The set supports DivX and MPEG4 video format.
You may change still picture display format on the

screen by selecting “Widescreen” or “Normal”
under “Display Format” option in the “General”
menu.

VII. Setting sleep

In TUNER or MUSIC mode, press SLEEP until

your desired sleep option is displayed.
➜ The current Tuner or Music playback will
continue.

OR,

In CLOCK or PHOTO/VIDEO mode, press

SLEEP until your desired sleep option is
displayed.
➜ The built-in relaxation music will start playback.

Helpful hint:
There are several built-in relaxation music, select

your desired one in the “Sleep Timer Music”
option of the “General” menu.

Wide screen

Normal

VIII. Brightness control

Press REPEAT ALARM /

BRIGHTNESS CONTROL

repeatedly to cycle

screen brightness through 4

levels.

IX. Screen auto dim

To avoid strong light emitting from the unit at
night time, the auto dim function can be used to
adjust the brightness to the lowest level
automatically.

To turn on auto dim, in the General menu, set On

in “Auto Dim Timer”, then set desired star t time in
“ Auto Dim Start”, and set desired end time in
“Auto Dim End”.
➜ During auto dim time span, press any button to
increase screen brightness, and it will last for 10
seconds.

X. Using the stand

The set is equipped with a stand on the bottom
panel. To set the unit for a different viewing angle,
take the stand out, then place it back by reversing
(see the figure below) the side of the stand.

IV. Switching off the alarm

During alarm call, press ALARM 1 or ALARM 2.

➜ is displayed.

OR,
Press REPEAT ALARM /

BRIGHTNESS CONTROL

.

to enable repeat alarm in 9 minutes.

To switch off alarm completely, press ALARM 1

or ALARM 2 repeatedly until is changed
to .
➜When alarm is deactivated, displays. When it
is activated, displays.

Helpful hint:
During alarm call, if no button is pressed, alarm call

will last 30 minutes.

To set the alarm sound with specific music, select

desired music in the “Alarm Music” of the Clock
menu.

V. Tuner

1. Press TUNER.
2. Press MENU.

➜The Tuner menu appears.

3. Press

4 to select “Tuner Auto Program”.

4. Press OK to star t the auto search and

programming.
➜ 20 available stations are programmed (FM).

5. Press

3 4 once or more to select your desired

station.

In TUNER mode, to turn off radio, press OK. To

turn on radio, press OK again.

To auto tune to a radio station, press and hold

press and hold

1 2 for about 2 seconds, then

release. (To store particular station, refer to
“Manual programming” of Tuner section in the
user manual.)

English

I. Connecting power

Connect the supplied mains adapter to the set’s

9V DC jack and the plug into a wall outlet.

II. Setting time and date

1. Press MENU.
2. Use

1 2 to highlight “Clock”.

3. Use

3 4 to select a field of “Time Set” and “Date

(Year-Month-Day)”.

4. Press OK to confirm.
5. Press or hold down

3 4 to set the values.

6. Press OK to confirm.
7. Repeat Steps 3-6 to set other values of “Time Set

and “Date (Year-Month-Day)”.

8. After finishing the setting, press CLOCK,

TUNER, PHOTO/VIDEO or MUSIC to exit
the setup menu.

Helpful hint:
In the clock mode, to zoom the picture displayed,
press and hold CLOCK for around 2 seconds, then
press OK repeatedly to enlarge picture or resume
to normal size, and use

1 2 3 4 to pan the

enlarged picture through. To exit the zoom mode,
press CLOCK again.

III. Setting/Activating alarm time

You can set two different alarm times.
1. Press CLOCK.
2. Hold down ALARM 1 or ALARM 2 for about 2

seconds, then release.

3. Press or hold down

3 4 to set hour.

4. Press ALARM 1 or ALARM 2 to confirm.
5. Press or hold down

3 4 to set minute.

6. Press ALARM 1 or ALARM 2 to confirm.
7. Press again ALARM 1 or ALARM 2 to activate

alarm setting.
➜When alarm is activated, displays.

Before zoom

After zoom

Thanks for buying Philips AJL308 clock radio.

Our Quick Start guides you through just some of the features on the set.

Please read our instruction booklet to really rise & shine!

AJL308

Register your product and get support at
www.philips.com/welcome

NOTES

Printed in China

Quick Start Guide

Guide de démarrage rapide

Guía de Inicio Rápido

AJL308_37_QSG_3L

7/25/08, 11:49

1
