English
Some monitors have mounting holes that are recessed. This kit includes longer Mounting Screws
(Parts B, C, H & I) and Spacers (Parts D & E) for this configuration. The spacers are used to take up
the space in the recessed hole as shown in Figure 3. The spacer you select must stick out past the
back of the TV to ensure proper mounting. You don’t want the spacer to be loose. The Monitor Plate
(MP) needs to rest securely on the spacers.
DETAILED VIEW
Back of TV
F
Selected
Long Screw
MP
D or E
Figure 3
