S a v e , C a n c e l , E X I T O S D , A N D R E S E T
How to Use the On Screen Display (OSD)
Sa Sa ve & R ve & R ec ec all all
F F rom a window rom a window
There are three ways to save your changes: by pressing the Front
Panel Button, by selecting S
AVE from the On Screen Display, or by
letting the On Screen Display time out. Each method saves the
changes you have made in a particular window.
For example, to make a change in the brightness, press the
B RIGHTNESS button on the front panel, make your change, then press
the B RIGHTNESS button again. (See page 4 for details.) You can also let
the display time out and the change will be saved. Note: Brightness,
Contrast, and Volume do not have
a S
AVE menu selection.
To cancel a change made in the
Brightness, Contrast, and Volume
windows individually, you must reenter each window and change the
setting.
Exit OSD & R Exit OSD & R eset eset
from the OSD from the OSD
Exiting from the On Screen Display removes the On Screen Display
from the monitor screen. Resetting from the On Screen Display returns
everything in all the windows to factory presets.
When you have finished work in any of the windows of the Main
Menu (even selecting M UTE O N / M UTE O FF ), you will return to the Main
Menu and E XIT OSD will be
highlighted. To exit, simply
press the O
N S CREEN D ISPLAY
button.
You can, however, use the
R
OTARY knob and scroll to
another menu item, for
example, A
DVANCED C ONTROLS . When A DVANCED C ONTROLS is
highlighted, press the O N S CREEN D ISPLAY button and that
window will replace the Main
Menu. You can now make
changes in that window. When
done, you will, again, return to
the Main Menu and E
XIT OSD
will be highlighted
Reset Entire On Screen Display
To Exit the entire On Screen Display
1 1
In some windows (S IZE & P OSITION and G EOMETRY ), you can save
all your changes at once. In the S IZE & P OSITION window, you can
make changes to each of the five items. When you are done,
highlight the S
AVE item and press the O N S CREEN D ISPLAY button. (See
pages 13 - 14 for details.) You can also let the display time out and
the change will be saved.
To cancel a change made in
the S
IZE & P OSITION window,
you can select C ANCEL from
the On Screen Display. If you
have made a change to only
one item – for example, Z
OOM – then only Z OOM will be changed back
to the previous setting. If more than one item has been changed, but
not saved individually, then all the items changed will be returned to
their previous settings. For example, if you made changes to Z
OOM ,
H ORIZONTAL S IZE , and V ERTICAL P OSITION and did not save them
individually, all three will be changed back when you select Cancel.
2 2
In some windows (A DVANCED C ONTROLS AND C OLOR T EMPERATURE ),
only individual saves are possible. For example, in the C OLOR
T EMPERATURE window, if you select U SER 1 and make changes (See
page 11 for details.), you must either save or cancel those changes
before moving on. While you could wait for the U
SER 1 window
(below) to time out, it is not recommended. Since you have not
formally saved this change as your selection, the next time you go
into the C
OLOR T EMPERATURE window, the screen will change to
selection (U SER 1, U SER 2, 9300˚ K, or 6500˚ K) last stored by using
S AVE . A checkmark
appears beside that
selection.
To cancel a change made
in C
OLOR T EMPERATURE (or
A DVANCED C ONTROLS ), select C ANCEL from the on screen display. Only
the last item changed will be changed back. All other items will
remain unchanged.
3 3
1 1
Selecting R ESET from
the Main Menu resets all
the changes you have made
in all the windows of the
Main Menu. For example, if
the language (See L
ANGUAGE ,
page 7.) has been changed,
it is taken back to English.
Use this feature only when you want to return all your
changes back to their original settings.
1 1
Exiting Brightnes Exiting Brightnes s, s,
V V ol ol ume, & Contr ume, & Contr ast ast
If you push the V OLUME , B RIGHTNESS , or C ONTRAST button to exit (See steps
3 on pages 4 and 5.) and find yourself in the Main Menu, follow the
steps below.
Turn the R OTARY
knob until Exit OSD is
selected, then press
the On Screen Display
button.
1 1
Always exit the V OLUME , B RIGHTNESS , or C ONTRAST On Screen
Displays by pressing the V OLUME , B RIGHTNESS , or C ONTRAST button
(steps 3 on pages 4 and 5).
2 2
