2
INSIDE THIS INSTRUCTION MANUAL
Important Safety Instructions / Specifications ..........................................................2
Important Information...................................................................................................3
Amplifier Descriptions..................................................................................................4
Set-up & Warranty Information....................................................................................5-7
Contact Information......................................................................................................8
1) Read these instructions.
2) Follow all instructions
3) Keep these instructions
4) Heed all warnings
5) Do not use the MATRIX 1000 near water. Be
extra cautious when moving the system during
rain or while transporting the system over wet
surfaces as water might splash onto the amplifier.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install
in accordance with manufacturer’s instructions.
8) Do not install near heat sources such as
radiators, stoves or other devices that may
produce heat.
9) Do not defeat the safety purpose of the
polarization or grounding-type plug. A
polarized plug has two blades with one wider
than the other. A grounding-type plug has two
blades and a third grounding prong. The wide
blade or the third prong is provided for your
safety. If the provided plug does not fit your
outlet, consult an electrician for replacement
of the obsolete outlet.
10) Protect the power cord from being walked on
or pinched, particularly at the plug and the
point where it exits the MATRIX 1000 amplifier.
11) Only use attachments / accessories specified
by B-52 Pro-Audio.
12) Use caution when transporting the system to
avoid injury from tip-over.
13) Unplug the MATRIX 1000 during lightning
storms and when not in use.
14) Refer all servicing to qualified to personnel.
Servicing is required when the MATRIX 1000
has been damaged in any way such as when
power-cord or plug is damaged, liquid has
been spilled into the cabinets, the unit has
been exposed to moisture or rain, does not
operate normally, or has been dropped.
15) To reduce the risk of fire or electric shock, do
not expose the MATRIX 1000 to rain or moisture.
16) The MATRIX 1000 is not intended for outdoor
fixed installations or in high moisture areas.
Moisture can damage the speakers and can
use cause corrosion of electrical contacts.
Keep speakers out of extended or intense
direct sunlight. The subwoofer spider and
surround will prematurely dry out and finished
surfaces may fade and be damaged by long-
term exposure to intense ultra-violent light.
IMPORTANT SAFETY INFORMATION
CAUTION CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
HEED ALL WARNINGS
WARNING: To reduce the risk or fire or
electrical shock do not expose this
equipment to rain or moisture.
Note: Specifications are subject to change without notice
CAUTION: Connect the power cable only after you have absolutely made
sure that the local mains voltage matches the voltage specified on the
device. If you connect to the wrong voltage, you may destroy the elec-
tronic components of the MATRIX 1000 system.
See page 4 for a complete description of factory-default voltage settings.
AMPLIFIER SPECIFICATIONS:
Subwoofer Power Output: 400 W / 8 Ohms @ 1% THD
10” Two-way Power Output: 150 W / 4 Ohms @ 1% THD
Line in: XLR Female
Parallel out: XLR Male
Input Impedance: 48 k Ohms
Speaker Out: Speakon NL4 Style Connector
Power Requirement: 115V<>50/60Hz<>10A
230V<>50/60Hz<>6A
ACTIVE CROSSOVER:
Crossover Frequency: 120 Hz; 24 dB/ Octave
SUBWOOFER:
Speaker: 1 x 15” Custom Built B-52 Subwoofer
Nominal Impedance: 8 Ohms
Subwoofer Freq. Response: 40 Hz – 120 Hz +/- 3dB
Sound Pressure Level (1w/1m): 102 dB (half space)
Max. SPL: 127 dB @10% THD
Weight: 115 lbs
Dimensions (Transport): 28” (H) x 19” (W) x 23” (D)
10” TWO-WAY SPEAKERS:
Speaker Input: Speakon style connector
(pin 1+ = +, pin 1- = -)
LF/MF Woofer: 1 x 10” Custom Built B-52 Transducer
HF Driver: 1 x 3/4” Titanium Diaphragm on CD Horn
HF Dispersion: 90 O x 40 O
Nominal Impedance: 4 Ohms
Active Freq. Response: 120 – 19K Hz +/- 3dB
Crossover Frequency (passive): 2.5 kHz; 12 dB / Octave
Sound Pressure Level (1w/1m): 101 dB (half space)
Max. SPL: 124 dB @10% THD
Weight: 25 lbs
Dimensions (Upright): 19” (H) x 12” (W) x 11” (D)
COMPLETE SYSTEM:
Weight: 165 lbs
Dimensions (Transport): 39” (H) x 19” (W) x 23” (D)
