Page 2

BEST BY BROAN
P.O. BOX 140 HARTFORD, WISCONSIN 53027
WM24E SERIES MOUNTING
WM24E SERIES WIRING
8
5
8
”
7
7
8
”
3
8
”
8
5
8
”
2
1
2
”
13
15
16
”
Support
Framing
Wall Studs
Support Board
Notes:
Minimum hood distance above the cook top must not be less than 23-3/8”.
A maximum of 29-3/8” above cook top is highly recommended for best capture of cooking impurities.
Distances over 29-3/8” are at the user’s discretion; and if ceiling height and flue lengths permit.
CEILING
HEIGHT
HOOD DISTANCE ABOVE 36" HIGH COOK TOP
23-3/8"
24-3/8"
25-3/8"
26-3/8"
27-3/8"
28-3/8"
29-3/8"
MOUNTING BRACKET LOCATION ABOVE 36" HIGH COOK TOP
8-Foot
44-7/8"
9-Foot
44-7/8"
45-7/8"
46-7/8"
47-7/8"
48-7/8"
49-7/8"
50-7/8"
10-Foot
44-7/8"
45-7/8"
46-7/8"
47-7/8"
48-7/8"
49-7/8"
50-7/8"
CONNECT:
WHITE-TO-WHITE,
RED-TO-BLACK,
GREEN-TO-GROUND
EXTERIOR OR
IN-LINE BLOWER
BOX MARKED
“MOTOR CONNECTION”
BOX MARKED
“120 VAC INPUT”
CONNECT:
WHITE-TO-WHITE,
BLACK-TO-BLACK,
GREEN-TO-GROUND
