7
Generac Portable Products 3000 PSI Pressure Washer
4. Secure handle to pressure washer using four provided
flange nuts.
5. Slowly tip pressure washer back in place and insert
multi–colored spray tips in spaces provided in handle.
Install Oil Dipstick on Pump
To install oil dipstick:
1. Make sure unit is on a level surface.
2. Remove and discard shipping cap located on pump
(Figure 2).
3. Install oil dipstick.
Add Engine Oil and Fuel
• Place pressure washer on a level surface.
• Refer to engine owner’s manual and follow oil and fuel
recommendations and instructions.
NOTE: Check oil often during engine break–in. Refer to
engine owner’s manual for recommendations.
Connect Hose and Water Supply to
Pump
IMPORTANT: To avoid pump damage, you must
assemble the nozzle extension to the spray gun and attach
all hoses before you start the engine.
1. Uncoil high pressure hose and attach quick connect
end of hose to base of spray gun (Figure 3). Pull down
on collar of quick connect, slide onto spray gun and let
go of collar. Tug on hose to be sure of a tight
connection.
NOTE: Remove and discard all pump shipping caps before
attaching hoses.
Figure 2 — Install Oil Dipstick onto the Pump
Shipping Cap
Pump Oil
Dipstick
Remove shipping cap and
install oil dipstick here.
CAUTION
• Failure to do so will void the warranty and damage the
pump.
You MUST remove the pump’s shipping cap and install
the oil dipstick.
CAUTION
• Refer to engine manual for oil and fuel fill information.
• Damage to equipment resulting from failure to follow this
instruction will void warranty.
Any attempt to crank or start the engine before it has
been properly filled with the recommended oil will result
in equipment failure.
Connect high
pressure hose
here.
Figure 3 — Connect High Pressure Hose to Spray Gun
