THERMOSTAT AND THERMIDISTAT CONTROL APPLICATION
NON-PROGRAMMABLE THERMOSTAT USAGE
* Model HP thermostat must be field converted to air conditioner operation.
† Must use Programmable Dual Fuel Thermostat or Thermidistat Control in this application.
‡ Dual Fuel operation controlled by heat pump when using Model 2S Thermostat.
Non-Programmable Models
The TSTATBBNAC01-B Thermostat provides single-stage, non-programmable heat/cool temperature control for 24-vac heating-
cooling systems with auto changeover. Temperature display can be selected to read °F or °C.
The TSTATBBNHP01-B Thermostat provides versatile 2-stage heating and single-stage cooling, non-programmable temperature
control for 24-vac heating-cooling systems with auto changeover. Temperature display can be selected to read °F or °C. Thermostat
comes factory set to operate as a heat pump model with second-stage controlling auxiliary electric heat. This model can easily be
converted from heat pump operation to air conditioning operation requiring 2 stages of gas or electric heat.
The TSTATBBN2S01-B Thermostat provides versatile multiple stage, non-programmable heat/cool temperature control for 24-vac
heating-cooling systems with auto changeover. Temperature display can be selected to read °F or °C. Thermostat is designed for
2-speed compressor bearing units. Thermostat comes factory set to operate as a heat pump model with 2-stage cooling and
3 stages of heat (third-stage controlling auxiliary electric heat). This model can easily be converted from heat pump operation
to air conditioning operation requiring 2 stages of cooling and 2 stages of heating.
PROGRAMMABLE THERMOSTAT USAGE
* Model HP thermostat must be field converted to AC operation.
† For use with special 3-stage electric heat setup.
‡ Dual Fuel operation controlled by heat pump when using Model 2S thermostat.
Programmable Models
The TSTATBBPAC01-B Thermostat provides single-stage, 7-day programmable heat/cool temperature control for 24-vac heating-
cooling systems with auto changeover. Temperature display can be selected to read °F or °C.
The TSTATBBPHP01-B Thermostat provides versatile 2-stage heating and single-stage cooling, 7-day programmable temperature
control for 24-vac heating-cooling systems with auto changeover. Temperature display can be selected to read °F or °C. Thermostat
comes factory set to operate as a heat pump model with second-stage controlling auxiliary electric heat. This model can easily be
converted from heat pump operation to air conditioning operation requiring 2 stages of gas or electric heat.
The TSTATBBP2S01-B Thermostat provides versatile multiple stage, 7-day programmable heat/cool temperature control for 24-vac
heating-cooling systems with auto changeover. Temperature display can be selected to read °F or °C. Thermostat is designed pri-
marily for 2-speed compressor bearing units. Thermostat comes factory set to operate as a heat pump model with 2-stage
cooling and 3-stages of heat (third-stage controlling auxiliary electric heat). This model can also perform Intelligent-Heat
staging with FK and FV fan coils (special heaters and setup required) using a single-speed heat pump with 3-stages auxiliary
electric heat. In addition, this model can easily be converted from heat pump operation to air conditioning operation requiring 2
stages of cooling and 2 stages of heating (e.g. gas or electric heat).
INDOOR UNIT
OUTDOOR UNIT
Air Conditioner Heat Pump
1 Speed 2 Speed 1 Speed 2 Speed
1-Stage Furnace Model AC or HP* Model 2S † Model 2S‡
2-Stage Furnace Model AC or HP* Model 2S † Model 2S‡
Typical Fan Coil Model AC or HP* Model 2S Model HP Model 2S
FK, FV Series Fan Coil Model AC or HP* Model 2S Model HP Model 2S
INDOOR UNIT
OUTDOOR UNIT
Air Conditioner Heat Pump
1 Speed 2 Speed 1 Speed 2 Speed
1-Stage Furnace Model AC or HP* Model 2S Model DF Model DF or 2S‡
2-Stage Furnace Model AC or HP* Model 2S Model DF Model DF or 2S‡
Typical Fan Coil Model AC or HP* Model 2S Model HP Model 2S
FK, FV Series Fan Coil Model AC or HP* Model 2S Model HP or 2S† Model 2S
