Philips 27RF70 User Manual

Quick use and setup guide, Asic, Elevision

background image

1

3121 233 41291

ANT 75

L

Monitor out

VIDEO

S-VIDEO

SURROUND SOUND

8

8

+ R – – L +

AV1 in

Y

Pb

Pr

AV2 in

AUDIO

R

M-Link

ANT 75

IN

OUT

1

2

Y

our Cable TV input into
your home may be a

single (75 ohm) cable or a
converter box installation.
In either case, the connec-
tion to the TV is very easy.
Just put the threaded end
of the cable signal to the
TV's antenna plug and
screw it down finger tight.

C

ABLE

TV

C

ABLE

I

NPUT

/C

ONVERTER

OR

OUT TO TV

IN FROM ANT.

1

ANT 75

L

Monitor out

VIDEO

S-VIDEO

SURROUND SOUND

8

8

+ R – – L +

AV1 in

Y

Pb

Pr

AV2 in

AUDIO

R

M-Link

ANT 75

2

F

ollow the steps to the
right to connect a

basic antenna or cable TV
signal to a VCR, and then
the VCR to the TV. For
information on other
hookups (possible when
cable/descrambler boxes
are included), refer to the
owner’s manuals for the
VCR and the cable con-
verter.

TV

TO

VCR

B

ASIC

C

ONNECTION

If your Cable TV signal

is a single, round cable
(75 ohm), then you're ready to
connect to the TV.
If you have a cable converter
box,
connect the cable TV signal
to the cable signal IN(put) plug
on the converter.

Connect the cable TV cable to the

ANTENNA/CABLE plug on the TV.
If you have a cable converter box,
connect the OUT(put) plug from the
converter to the 75

(ohm) plug on the

TV.

Connect your anten-

na or cable TV signal to the
IN FROM ANT(enna)
plug on
the VCR.

Connect the OUT TO

TV plug on the VCR to the
75

(ohm) plug on the TV

(connecting cable supplied
with the VCR).

Back of TV

Round Cable

75

(Ohm)

Cable TV Converter

Box Connection

Cable TV Company

Remember
to set the TV for the
type signal to which
you've just connect-
ed (see the “Tuner”
section on page 3).

To select only the
channel numbers on
your cable system,
see “Auto Program”
(page 3). If you use a
cable converter box,
set the TV to the
same channel as the
converter's CH 3/4
switch (on the back
of the converter).

S

MART

H

ELP

Cable TV Signal Input

Round Cable

75

(Ohm) Supplied with VCR

Outdoor

VHF/UHF

Antenna

300

(Ohm) to

75

(Ohm) Adapter

Cable TV signal

Back of TV

Refer to the owner's

manual included with your
VCR for other possible con-
nections and TV/VCR operat-
ing details.

OR

NOTE: The connecting cable
for the converter is supplied
by the cable TV company.

VCR

1

ANT 75

L

Monitor out

VIDEO

S-VIDEO

SURROUND SOUND

8

8

+ R – – L +

AV1 in

Y

Pb

Pr

AV2 in

AUDIO

R

M-Link

ANT 75

2

A

combination antenna
receives normal broad-

cast channels (VHF 2–13
and UHF 14–69). Your
connection is easy because
there is only one 75

(ohm) antenna plug on the
back of your TV, and that’s
where the antenna goes.

A

NTENNA

C

OMBINATION

UHF/VHF

Remember, be
sure to set the TV for
the type of signal to
which you've connected
(see the “Tuner” section
on page 3).

To set the TV to select
only the channel num-
bers in your area, see
how to “Program” or
“Add” channels in mem-
ory on page 3 (“Auto
Program” section).

Contact your dealer,
or call our Parts
Information Center at
1-800-851-8885 to order
the following acces-
sories:

• 300

(ohm) to 75

(ohm) adapter

• Combination

VHF/UHF antenna.

S

MART

H

ELP

If your antenna has a

round cable (75 ohm) on the end,
then you're ready to connect it to
the TV.
If your antenna has flat, twin-
lead wire
(300 ohm), you first need
to attach the antenna wires to the
screws on a 300- to 75-ohm
adapter.

Push the round end of the

adapter (or antenna) onto the
75

(ohm) plug on the back of

the TV. If the round end of the
antenna wire is threaded, screw
it down finger tight.

300

(Ohm) to

75

(Ohm) Adapter

Combination VHF/UHF

Antenna

(Outdoor or Indoor)

Twin–Lead

Wire

Round Cable

75

(Ohm)

Back of TV

OR

NOTE: For homes with separate UHF and
VHF antennas, you will need an optional com-
biner to connect to the TV.

ANT 75

L

Monitor out

VIDEO

S-VIDEO

SURROUND SOUND

8

8

+ R – – L +

AV1 in

Y

Pb

Pr

AV2 in

AUDIO

R

M-Link

U/V

Combiner

300- to 75-Ohm Adapter

Back of TV

T

ABLE OF

C

ONTENTS

Getting Started

Warning/Important Notice . . . . . . . . . . . . .1

Basic Cable Television Connection . . . . . . .1

Basic Antenna Television Connection . . . . . . . . . . . .1

Basic VCR/Accessory Device Connection . . . . . . . .1

Basic Television Operation . . . . . . . . . . . . . . . . . . . .2

Basic Remote Control Operation . . . . . . . . . . . . . . .2

How to Use the Installation Features . . . . . . . . . . .3-4

Using the Language Control . . . . . . . . . . . . . . . . . .3

Setting the Tuner Mode Control . . . . . . . . . . . . . . .3

How to Automatically Program Channels . . . . . . . .3

How to Add and Delete Channels . . . . . . . . . . . . . .4

How to Name (Label) Channels . . . . . . . . . . . . . . . .4

How to set the AutoChron™ Feature (Clock) . . . . . .4

Quick Use and Setup Guide

12

1

2

3

4

5

6

7

8

9

10

11

B

ASIC

T

ELEVISION

C

ONNECTIONS

Quick Use and Setup Guide

IMPORTANT

NOTE: This owner's manual is used with several
different television models. Not all features (and
drawings) discussed in this manual will necessar-
ily match those found with your television set.
This is normal and does not require you contact-
ing your dealer or requesting service.

WARNING: TO PREVENT FIRE OR SHOCK
HAZARD DO NOT EXPOSE THIS UNIT TO
RAIN OR EXCESSIVE MOISTURE.
