Parts Bag Contents
1 Adjuster arm lock pin
1 10 X 8 mm hexagonal nut
1 Door locking plate
1 Door handle
2 10 X 8 mm hexagonal nuts
2 Washers
2 10 X 85 mm Phillips hex head bolts
2 Upper hinges
2 Lower hinges
4 6 X 5 mm hexagonal nuts
4 6 X 45 mm Phillips head bolts
2 6 X 15 mm Phillips head bolts
12 6 X 12 mm Phillips head bolts
2 Cotter pins
2 Hood pivot pins
8 6 X 5 mm hexagonal nuts
8 6 X 28 mm Phillips head bolts
1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
10
11 12 13 14 15 16 17
2 3 4 5 6 7 8 9
