BKI LPF-F User Manual
Page 43
Electric Pressure Fryer
Replacement Parts
41
Figure 10. Quick Disconnect Assembly
Table 10. Quick Disconnect Assembly Parts
ITEM #
PART #
QTY
DESCRIPTION
AB86200700
1 B0996
1
BALL, 11/16" STEEL BEARING
2 FT0429
1
QUICK DISCONNECT, PUMP SIDE
3 FT0500
1
QUICK DISCONNECT, VAT SIDE
4 FT0536
1
COUPLING, 5/8 45¦ FLARE TO
5 O0013
2
O-RING, FLUOROCARBON V680-70
6 O0014
1
O-RING, PARKER #2-124 LARGE
7 S0138
1
SPRING, FOR QUICK DISCONNECT
8 SCR453
2
SCREW, #10 24X3/8" WASHERED
SB1997S
1 B0996
1
BALL, 11/16" STEEL BEARING
2 FT0429
1
QUICK DISCONNECT, PUMP SIDE
3 FT0500
1
QUICK DISCONNECT, VAT SIDE
5 O0013
2
O-RING, FLUOROCARBON V680-70
6 O0014
1
O-RING, PARKER #2-124 LARGE
7 S0138
1
SPRING, FOR QUICK DISCONNECT
