Local and remote units: ACS2209A-R2-MM
or AC2209A-R2-SM
T e c h S p e c S
Distance —
ACS2009A-R2, ACS2209A-R2, ACS4001A-R2, ACS4201A-R2:
24 AWG: 400 ft. (121.9 m);
26 or 28 AWG: 200 ft. (61 m);
ACS2009A-R2-MM, ACS2209A-R2-MM, ACS4001A-R2-MM,
ACS4201A-MM-R2: 1312.3 ft. (400 m);
ACS2009A-R2-SM, ACS2209A-R2-SM, ACS4001A-R2-SM,
ACS4201A-R2-SM-R2: 6.2 mi. (10 km)
Resolution (Maximum) — 1920 x 1200 @ 60 Hz
CE Approval — Yes
Connectors —
ACS2009A-R2:
Local unit: Keyboard and mouse: (1) 6-pin mini-DIN F;
Monitor: (2) DVI-D F; Interconnect: (1) RJ-45;
Remote unit: Keyboard and mouse: (2) 6-pin mini-DIN F;
Monitor: (1) DVI-D F; Interconnect: (1) RJ-45;
ACS2209A-R2:
Local unit: Keyboard and mouse: (1) 6-pin mini-DIN F;
Monitor: (4) DVI-D F; Interconnect: (2) RJ-45;
Remote unit: Keyboard and mouse: (2) 6-pin mini-DIN F;
Monitor: (2) DVI-D F; Interconnect: (2) RJ-45;
ACS4001A-R2:
Local unit: Keyboard and mouse: (1) USB Type B F;
Monitor: (2) DVI-D F; Interconnect: (1) RJ-45;
Remote unit: Keyboard and mouse: (2) USB Type A F;
Monitor: (1) DVI-D F; Interconnect: (1) RJ-45;
ACS4201A-R2:
Local unit: Keyboard and mouse: (1) USB Type B F;
Monitor: (4) DVI-D F; Interconnect: (2) RJ-45;
Remote unit: Keyboard and mouse: (2) USB Type A F;
Monitor: (2) DVI-D F; Interconnect: (2) RJ-45;
ACS2009A-R2-MM, ACS2009A-R2-SM:
Local unit: Keyboard and mouse: (1) 6-pin mini-DIN F;
Monitor: (2) DVI-D F; Interconnect: (1) pair of LC;
Remote unit: Keyboard and mouse: (2) 6-pin mini-DIN F;
Monitor: (1) DVI-D F; Interconnect: (1) pair of LC;
ACS2209A-R2-MM, ACS2209A-R2-SM:
Local unit: Keyboard and mouse: (1) 6-pin mini-DIN F;
Monitor: (4) DVI-D F; Interconnect: (2) pair of LC;
Remote unit: Keyboard and mouse: (2) 6-pin mini-DIN F;
Monitor: (2) DVI-D F; Interconnect: (2) pair of LC;
ACS4001A-R2-MM, ACS4001A-R2-SM:
Local unit: Keyboard and mouse: (1) USB Type B F;
Monitor: (2) DVI-D F; Interconnect: (1) pair of LC;
Remote unit: Keyboard and mouse: (2) USB Type A F;
Monitor: (1) DVI-D F; Interconnect: (1) pair of LC;
ACS4201A-R2-MM, ACS4201A-R2-SM:
Local unit: Keyboard and mouse: (1) USB Type B F;
Monitor: (4) DVI-D F; Interconnect: (2) pair of LC;
Remote unit: Keyboard and mouse: (2) USB Type A F;
Monitor: (4) DVI-D F; Interconnect: (2) pair of LC
Operating Environment — Temperature: 41 to 113°F (5 to 45°C);
Humidity: Up to 80% noncondensing
Power — 90–240 VAC, 47–63 Hz, autosensing, external, with IEC 320
connector and cord
Size — Single DVI local and remote units:
1.1"H x 4"W x 5.6"D (2.8 x 10.2 x 14.2 cm);
Dual DVI local and remote units:
1.6"H x 4"W x 5.6"D (4.1 x 10.2 x 14.2 cm)
weight — Local and remote units: 1.3 lb. (0.6 kg) each
Item Code
ServSwitch DVI CATx KVM Extenders
for PS/2 Keyboards and Mice
Single DVI ACS2009A-r2
Dual DVI ACS2209A-r2
for USB Keyboards and Mice
Single DVI ACS4001A-r2
Dual DVI ACS4201A-r2
ServSwitch DVI Fiber Optic KVM Extenders
for PS/2 Keyboards and Mice
Single DVI, Multimode ACS2009A-r2-MM
Single DVI, Single-Mode ACS2009A-r2-SM
Dual DVI, Multimode ACS2209A-r2-MM
Dual DVI, Single-Mode ACS2209A-r2-SM
for USB Keyboards and Mice
Single DVI, Multimode ACS4001A-r2-MM
Single DVI, Single-Mode ACS4001A-r2-SM
Dual DVI, Multimode ACS4201A-r2-MM
Dual DVI, Single-Mode ACS4201A-r2-SM
