English
-3-
Parts Identification
1 Motor housing
2 Latch – left
3 Latch – right
4 Sieve housing
5 Pulp container
6 Spout
7 Cover
8 Inlet chute
9 Pusher
10 Pusher (round)
11 Inlet chute adaptor
12 Sieve
13 Plug & cord set
14 Sieve adaptor
15 Switch
Note: The Juicer will not operate unless all the parts (pulp container (5), sieve housing (12),
latches (2,3) and cover (7)) are correctly fitted.
Note: The sieve will continue to rotate after the appliance has been turned off.
Note: Do not approach any parts that move in use. Allow the motor to come to a complete
stop before removing any part of the appliance.
FEATURES
• 600W
• 2 speed operation
• Removable pulp container
• Full apple inlet
• Stainless steel sieve
1
13
15
14
2
4
5
6
7
12
11
8
10
11
9
3
