12
CONNECTING PROJECTOR
ON
1
DIP
ON
OFF
2 3 4 5 6
13" MODE (640 x 480)
16" MODE (832 x 624)
19" MODE (1024 x 768)
OFF ON ON
ON ON
ON ON
OFF OFF OFF
OFF OFF OFF OFF
OFF OFF OFF OFF
1 2 3 4 5 6
OFF OFF ON ON ON ON 21" MODE (1152 x 870)
CONTROL PORT
USB
RESET
Y – Pb / Cb – Pr / Cr R – AUDIO IN – L (MONO)
S – VIDEO
COMPUTER IN MONITOR OUT
EXT.SP(8 Ω)
(STEREO)
AUDIO IN
COMPUTER
VIDEO
CONNECTING TO COMPUTER
IBM-compatible computer or Macintosh computer (VGA / SVGA / XGA / SXGA)
VGA Cable
Monitor Output
Desktop type Laptop type
External Speaker
Control Cable
for Serial Port ✽
Audio Cable
(stereo) ✽
Terminal
Serial port PS/2 port Audio Output
Audio Input
CONTROL PORT
EXT. SP(8 Ω)(STEREO)
AUDIO IN COMPUTER
COMPUTER IN
Use one of these Control
Cables corresponding with
the terminal of your
computer.
ADB port
Cables used for connection ( ✽ = Cable or adapter is not supplied with this projector.)
Control Cable
for PS/2 Port
Control Cable
for ADB Port ✽
Audio
Cable
✽
(stereo)
NOTE :
When connecting the cable, the power
cords of both the projector and the external
equipment should be disconnected from
AC outlet. Turn the projector and
peripheral equipment on before the
computer is switched on.
USB port
MAC Adapter ✽
Set slide switches
according to the
chart below.
• VGA Cable (HDB 15 pin)
• Control Cable for PS/2 Port
• Control Cable for Serial Port
✽ , or ADB Port ✽
• USB Cable ✽
• MAC Adapter (When connecting to Macintosh computer) ✽
• Audio Cables (Mini Plug (stereo) x 1) ✽
Speaker Terminal
Terminals
of the Projector
Terminal Terminal
MONITOR OUT
USB
Set switches as shown in the table
below depending on RESOLU-
TION MODE that you want to use
before you turn on projector and
computer.
◆ MAC ADAPTER (Not supplied)
USB
Cable
✽
Monitor Input
VGA Cable ✽
