M
aintenance and care
10
Cleaning the dirt cup filters (cont)
6. Attach the dirt cup filter back onto
the filter frame base by lining up
the tabs on the filter base with
the notches on the dirt cup filter
and turning clockwise to lock back
into place.
7. Attach the dirt cup filter screen back
on to the dirt cup filter by sliding it
down over the dirt cup filter, making
sure that the tabs on the bottom of
the dirt cup filter screen line up with
the notches on the dirt cup filter.
8. Insert the dirt cup filter assembly
back into the dirt cup by lining up
the tabs on the top of the dirt cup
filter assembly with the notches
inside the top of the dirt cup and
turning the handle on the bottom of
the dirt cup filter assembly clockwise
to lock into place.
