Initial Setup:
1. Unpack system and put
aside all packing materials.
Unfold the lighting arms until
reach the end position.
2. Raise the main camera arm
until it locks in place, then
rotate the upper camera arm.
3. Rotate the camera head
until the lens face the center
of the base unit.
4. Connect RGB interface: use the provided RGB cable, connect the output of the
visual presenter with the RGB input the display (monitor, television or projector).
5.
Connect the composite-in interface: use the provided RCA pin cable. Plug the
power cord into the power cord receptacle of the visual presenter and the AC outlet.
