The RBRC™ Seal

The RBRC™ Seal on the nickel-cadmium battery pack indicates

that this product is voluntarily participating in an industry

program to collect and recycle these battery packs at the end of

their useful life, when taken out of service within the United

States. The RBRC™ program provides a convenient alternative

to placing spent nickel-cadmium battery packs into the trash or

municipal waste stream which is illegal in some areas.
The RBRC™program makes it easy for you to drop off the spent battery pack at

local retailers of replacement nickel-cadmium batteries. You may also contact

your local recycling center for information on where to return the spent battery

pack.
RBRC™ is a trademark of the Rechargeable Battery Recycling Corporation..

Battery Removal

Before attempting to disassemble this tool, turn it on and run it in either direction

until it stops to ensure a complete discharge of the batteries.
Use a flat bladed screwdriver to pry up the locking clip, as shown in Figure 3.

Remove the locking clip from the tool. Pull the gear case off of the tool.
Take the two body halves apart and you will find the batteries.
Lift the batteries out and pull off the terminal clips.

MAINTENANCE

Use only mild soap and damp cloth to clean the tool. Never let any liquid get

inside the tool; never immerse any part of the tool into a liquid.
IMPORTANT:

To assure product SAFETY and RELIABILITY, repairs, maintenance

and adjustment should be performed by authorized service centers or other

qualified service organizations, always using identical replacement parts.

Lubrication

MASTER MECHANIC tools are properly lubricated at the factory and are ready

for use.

AVOID UNINTENTIONAL STARTING. Don’t carry tool with finger on the switch.

Be sure the switch is off when charging.

STAY ALERT. Watch what you are doing. Use common sense. Do not operate

tool when you are tired.

CAUTION:

When drilling or driving into walls, floors or wherever live electrical

wires may be encountered, DO NOT TOUCH ANY METAL PARTS OF THE

TOOL! Hold the tool only by the plastic handle to prevent shock.

SAVE THESE INSTRUCTIONS FOR FUTURE USE

Charging Notes

NOTE:

The tool was sent from the factory in an uncharged condition. Before

attempting to use it, it must be charged for 12 hours.

1. Charger will work best at normal room temperature.
2. The charger plug and the tool handle may become warm while charging.

This is normal and does not indicate a problem.

3. The tool can be left on charge as long as you desire. A minimum charge

time of 12 hours is required to recharge a completely discharged tool.

4. For most fix up jobs a charge of 3 to 4 hours will be adequate.

MOUNTING

Refer to Figure 1 for wall mounting instructions.

Switch

To turn the tool ON in a forward direction, (driving fasteners or drilling holes),

slide the switch button to the right and align it with the arrow pointing forward.
DEPRESS

the SWITCH button and the tool will run. Release the switch button and

the tool will stop.
To operate in reverse (removing fasteners or backing out a jammed drill bit) slide

the switch button to the left and align it with the arrow pointing backward.
DEPRESS

the SWITCH button and the tool will run. Release the button and the

tool will stop.
With the switch button in any of its 3 positions and NOT depressed, the tool will

lock and act as any conventional, non-powered screwdriver. This feature is

useful for giving an extra twist to screws to tighten them firmly or loosen extra

tight ones.

3

E

NGLISH

386230/TV100 11/14/03 7:32 AM Page 3
