B&C Speakers Horns ME45 User Manual
Me45, Horns, Specifications
ME45
Horns
LF Drivers
LF Nd Drivers
Coaxials
HF Drivers
Horns
1” throat entry
90° x 40° nominal coverage
Exponential flare
Very good loading down to 1 kHz
Specifications
Throat Diameter (1)
25 mm (1 in)
Nominal Coverage Horizontal
90°
Nominal Coverage Vertical
45°
Cutoff Frequency
1 kHz
Material
Cast Aluminium
Dimensions
310x140x124 mm
(12.2x5.6x4.9 in)
Mounting and Shipping Info
Two 6 mm (0.25 in) holes 180°
on 76 mm (3 in) diameter
Baffle Cutout Dimensions
260x110 mm (10.2x4.3 in)
Net Weight (1 unit)
0.8 kg (1.8 lb)
Shipping Weight (4 unit)
4.9 kg (10.8 lb)
Shipping Box (4 unit)
540x350x185 mm
(21.2x13.8x7.3 in)
1
Horn mounted on B&C DE25 compression driver
