GOOSENECKS
Condenser Gooseneck Microphone
GCU250
Slim and unobtrusive in design, this high-performance gooseneck provides smooth, noise-
less, and precise microphone positioning. It exudes a speech-tailored frequency response
with rich treble and bass. Minimal ambient and handling noise with high intelligibility
to cut through noisy backgrounds and large gatherings. Reliable and efficient for clean,
accurate vocal reproduction. Features integral windscreen, and an XLR connector located
under mounting base. (18 - 1/2" Long, 4 oz.)
• 5-1/2" adjustable lower stalk, with 9-1/2" rigid upper section
• Heavy all-metal case with non-glare black finish
• Ultra-compact, rugged design
• Cardioid pickup pattern
• Electret condenser element
• Phantom power operated (9 -52V DC)
• 250-ohm impedance
• Wide frequency response range of 50 Hz - 18 kHz
• Sensitivity of -65 dB +/- 3 dB
Dynamic Gooseneck Microphone
GDU150
Attractive and elegant in design, this gooseneck microphone allows for smooth noise-
less microphone positioning. Outstanding speech intelligibility, feedback rejection, user
sound isolation, high sound pressure capability, and low sensitivity to breath/pop noise.
Features a superior shock-mount system to reject handling and transmission noise, a
built-in locking push-button on/off switch, and an integral multi-layer breath/wind filter.
(16 - 3/4" Long, 11 oz.)
• 10" long, fully flexible neck
• Durable all-metal case with non-glare black finish
• Rugged, reliable construction
• Cardioid pickup pattern
• Dynamic element
• 500-ohm impedance
• Wide frequency response range of 100 Hz - 12 kHz
• Sensitivity of -75 dB +/- 3 dB
Industrial Gooseneck Microphone
MGN19
Designed to stand up under the most strenuous handling conditions, this gooseneck is
extremely reliable and provides a natural crisp, highly-intelligible sound. Features four
conductor, two-shielded, permanently attached, synthetic jacketed cable, and a DPDT
push-to-talk button-operated sealed microswitch mounted on the microphone housing.
(23- 1/2" Long, 1 -1/4 lb.)
• 19" flexible neck with mounting flange
• Chrome-plated screen and gooseneck,
black plastic cap and housing
• Durable, rugged construction
• Omni-directional pickup pattern
• Dynamic element
• 400-ohm impedance
• Frequency response is uniform from
50 Hz - 12 kHz with 2 kHz boost
• Sensitivity of -76 dB +/- 3 dB
