2
Introduction
Boston Acoustics Multi-Channel Solution
Thank you for choosing a Boston Acoustics Multi-Channel Solution speaker. These speakers incorporate high-quality compo-
nents that produce the famous Boston sound. They are ideally suited for use in a 5.1 channel high-quality home theater or
music system.
The MCS series speakers deliver exceptionally articulate on-screen dialog, music, eff ects, and room fi lling bass from a small,
sleek package. Compact driver placement and quality, system specifi c crossovers ensure wide, uniform sound dispersion
for complete coverage of a listening room. All speakers also feature MagnaGuard® magnetic shielding which ensures the
speaker’s magnetic fi eld does not interfere with the televisions picture.
Specifi cations
MCS 100 MCS 130 MCS 130
Satellite Speaker Surround Speaker LCR Speaker
Frequency Response: 120Hz – 20kHz 120Hz – 20kHz 110Hz – 20kHz
Recommended Amplifi er 10 – 100 watts 10 – 150 watts 10 – 150 watts
Power Range:
Sensitivity: 88dB [2.8v at 1m] 88dB [2.8v at 1m] 88dB [2.8v at 1m]
Nominal Impedance: 8 ohms 8 ohms 8 ohms
Crossover Frequency: 3,000Hz 2,700Hz 2,700Hz
Midrange: 3 ” (76mm) 3 1 / 2 ” (89mm) Dual 3 1 / 2 ” (89mm)
treated fi ber with copolymer DCD™ with copolymer DCD™ with
Phase Plugs and Phase Plugs and Phase Plugs and
MagnaGuard® MagnaGuard® MagnaGuard®
Tweeter: 3 / 4 ” (19mm) 1” (25 mm) 1” (25 mm)
Kortec® Soft Dome Kortec® Soft Dome 1” Kortec Soft Dome
Dimensions: (H x W x D) 7 3 ⁄
8
x 4 3 ⁄
8
x 4 11 ⁄
16
” 8 7 ⁄ 16 x 5 1 ⁄ 2 x 4” 13 7 ⁄ 8 x 5 x 4 1 ⁄ 16 ”
(189 x 113 x 93mm) (214 x 140 x 102mm) (351 x 125 x 103mm)
Weight: 2 1 / 2 lbs 3 lbs 5 lbs
(1.14kg) (1.36kg) (2.27kg)
