background image

Part No. 830542

Form No. F021302G

Page 10 of 16

PARTS

LIST

19

VQ1002SP

VQ802SPH

PART NO.

QTY

PART NO.

QTY

1

ENGINE 10 HP INTEK B&S

430352

1

-

-

ENGINE 8 HP HONDA

-

-

400937

1

2

ANGLE MOUNT HDLE W A

830126

1

830126

1

3

IMPELLER ASSY VQ (INCLUDES ITEM 4,5,6,7)

830244

1

830244

1

4

KEY 0.25 SQ. X 2.75"

9201125

1

9201125

1

5

W ASHER LOCK 7/16 TW ISTED TOOTH

850132

1

850132

1

6

SCREW CAP 7/16 NF x 2 1/4 GR8 TORQ 60 FT LBS (81.4 N.m)

830114

1

830114

1

7

SPACER ENGINE

830113

1

830113

1

8

CLIP LOCK

400591

1

400591

1

9

SCREW CAP 5/16 NF x 2 1/2 GRD. 8

830136

2

830136

2

10

HOUSING ASSEMBLY W /LABELS VQ

830153

1

830153

1

11

FRAME W A VQ

830171

1

830171

1

12

NOZZLE ASSEMBLY VQ

830010

1

830010

1

13

NOZZLE ASSY W /LABELS

830181

1

830181

1

14

CAP PLUG VQ

830232

1

830232

1

15

PLATE DOOR NOZZLE HOSE

830193

1

830193

1

16

ROD DIVERTER VQ

830194

1

830194

1

17

GROMMET FLG. 1/2 MOLDED

830176

2

830176

2

18

BRKT BOGIE ASSY LH

830197

1

830197

1

19

BRKT BOGIE ASSY RH

830198

1

830198

1

20

BRKT BOGIE W A LH

830199

1

830199

1

21

BRKT BOGIE W A RH

830200

1

830200

1

22

ROLLER GUIDE

850204

2

850204

2

23

PIN ROLLER

850205

2

850205

2

24

W HEEL BOGIE 3"

850149

2

850149

2

25

SPACER 5/16 X 1 5/8

850150-03

2

850150-03

2

26

CASTER & BRKT LH ASSY SEMI-PNEU VQ

830540

1

830540

1

27

CASTER & BRKT RH ASSY SEMI-PNEUVQ

830541

1

830541

1

28

BRKT LH W A 8" CASTER

830147

1

830147

1

29

BRKT RH W A 8" CASTER

830148

1

830148

1

30

CASTER ASSY 8" SEMI-PNEU 3/4 NC (INCL ITEM 33 (4), 94, 95, 96, 125, 134)

830539

2

830539

2

31

KNOB HAND

850154

2

850154

2

32

NUT W ING W A

800227

2

800227

2

33

W ASHER 3/4 NYLON

800109

2

800109

2

34

ELBOW ASSY W /LABELS VQ

830159

1

830159

1

35

GASKET FLANGE TRANSITION VQ

830160

1

830160

1

36

HANDLE BRACE REAR

830162

1

830162

1

37

HANDLE LOW ER VQ

830161

1

830161

1

38

TUBE HANDLE BAG SUPPORT

830163

1

830163

1

39

ROD BAG LOOP

800178

2

800178

2

40

CAP TUBE

800392

2

800392

2

41

HANDLE ASSY UPPER W /GRIP (39, 45, 46, 81, 114, 115, 131, 163)

890295

1

890295

1

42

SW ITCH & W IRE ASSY(ITEMS 107,109,110)

-

-

830242

1

43

CONTROL THROTTLE ASSY VQ SERVICE

900514-00

1

830132

1

44

CLAMP CABLE 1"

900813

4

900813

4

45

DOOR NOZZLE FRICTION ASSY

830288

1

830288

1

46

SPACER

850198

2

850198

2

47

ROD DOOR NOZZLE

830286

1

830286

1

48

BAR LEVER DOOR

850189

1

850189

1

49

PLATE FRICTION LIFT

850191

1

850191

1

50

BAG ASSY VQ / TURF BAG 830282

830320

1

830320

1

51

AXLE REAR W A PUSH

-

-

-

-

DIFFERENTIAL ASSY / SPROCK. ONLY 830021

830014

1

830014

1

52

W ASHER HUB CAP

850237

2

850237

2

53

CAP HUB

900486

2

900486

2

54

W HEEL 13" x 6.5" PNEU. SP

830177

2

830177

2

55

BRG ASSY VQSP

850232

2

850232

2

56

BRKT MOUNT BEARING

830530

2

830530

2

57

TRANSMISSION 5 SPEED 1 REV W /BRAKE (TECUMSEH)

830179

1

830179

1

58

CHAIN #41 x 68P VQSP

830020

1

830020

1

59

BELT “V” 4L x 34" OUTSIDE LG.

830223

1

830223

1

60

PULLEY 5.0 DIA. A SEC 0.625 ID

830180

1

830180

1

61

KEY HIPRO 3/16 X 3/4

850234

1

850234

1

62

PULLEY IDLER

800260

1

800260

1

63

BOLT IDLER

800888

1

800888

1

64

ARM IDLER W A VQ

830527

1

830527

1

65

SPRING

400217

1

400217

1

ITEM DESCRIPTION
