Bosch 0601045639 - Manual (Page 2)

1 2 610 998 101 Motor Housing 71
2 2 610 967 181 Field 22
3 2 610 998 164 Armature w/Fan AW
4 2 610 998 107 Switch VSR 17
5 2 610 998 127 Cord 11
6 2 600 703 013 Strain Relief 11
7 2 601 035 001 Cord Clamp 89
8 2 610 998 430 Nameplate 9
9 2 610 998 418 Lable "Bosch" 9
13 2 610 351 861 Ball Bearing 60
14 1 900 905 018 Ball Bearing 61
16 2 604 337 003 Brush Holder {2} 25
19 2 610 315 386 Screw {2} 89
21 2 610 907 525 Screw 89
22 2 610 998 102 Handle Cover 74
23 2 610 998 118 Grounding Strap 10
26 2 910 615 082 Screw {3} 89
29 2 610 998 115 Baffle 24
30 3 602 391 503 Rubber Buffer {2} 66
34 2 610 998 132 Spacer 82
35 2 610 346 444 Reversing Screw LH 85
36 2 610 906 123 1/2" Keyed Chuck 91
37 2 914 411 045 Screw {2} 89
38 2 910 615 022 Screw {3} 89
40 2 610 998 138 Cable 10
41 2 610 998 117 Gasket 79
44 2 610 998 128 Retaining Ring 89
45 2 610 968 044 Ball Bearing 56
49 2 600 914 010 Needle Bearing {2} 56
51 1 600 910 018 Needle Bearing 56
52 2 910 611 405 Screw {4} 89
53 2 610 998 133 Cable 10
54 2 610 998 134 Cable 10
55 2 610 998 135 Cable 10
56 2 610 998 136 Cable 10
57 2 610 998 137 Cable 10
58 2 610 998 114 Lock-On Lever 64
59 2 610 998 116 Spring 27
60 2 610 998 113 Reversing Lever 64
61 2 600 100 607 Shim 0.3mm 65
+ 651 2 610 304 790 Key Holder 9
652 2 610 348 635 Chuck Key 91
653 2 602 025 094 Handle Assembly 74
w/pos. 653/2, 653/3
653/2 2 915 011 007 Nut 89
653/3 1 613 480 007 Wing Screw 89
810 2 604 321 914 Brush Set 26
825 2 610 998 144 Gear Housing Assembly 72
w/pos. 49
828 2 610 998 153 Intermediate Plate Assy. 38
w/pos. 49, 51
842 2 610 907 368 Spindle w/Gear Assembly 32
847 2 610 998 147 Intermediate Gear Assy. 31
864 2 610 907 408 Eccentric w/Washer Assy. 34
Pos. Part Number Description {Qty.} F/C Pos. Part Number Description {Qty.} F/C
+ = Not Illustrated * = As Required F/C = Failure Code AW = Refer to AW Labor Time Chart
Service Notes:
1013VSR
1/2" DRILL
