BT PaperJet 50e User Manual
Page 11
11
IMPORTANT NOTE
Before connecting to the mains power remove the
red tag marked “REMOVE before plugging in” by
pulling in the direction of the arrow.
5
Connect the mains power
Plug into the mains power and switch on.
The fax will automatically carry out a short test to
check the functions of its components and the
following messages will appear in the display:
AUTOMATIC RX
CHECK PRINT HEAD
and alternating
SET DATE/TIME
6.
Load paper
The plain paper sheet feeder can hold up to 40 sheets
of 80gsm paper.
It can accommodate A4 (210 x 297mm), US Letter
(216 x 279mm), and US Legal (216 x 356mm) and
weights between 70-90gsm.
Place the paper in the sheet feeder. Do not force it in.
Use the paper width adjustment lever to push the
paper against the left side of the feeder.
Maximum Level
NOTE
When you need to add more paper, always slide it
under the paper that’s already loaded.
