Bunn Brewise 39132 - Manual (Page 6)

Page 6
SERVICE PROGRAMMING
MAY 10 2010
MAIN 10:00:00 AM
This allows you to monitor the frequency of the warmer(s) sensing
coils.
Also allows you to monitor the adjustment capacitors, which are used
to keep the coil frequency at it's nominal value (125.0 khz)
Use the "Brewer" button to toggle between screens.
Press right hidden button to advance to next function.
125.0 0000 * TOP F
125.0 0000 * TOP R
This allows you to read the "age" of any brewed batch in a particular
carafe (as long as it is equipped with an RFID chip). The sensor coil
will read the chip and brewer will display time of day it was brewed.
DISPLAY BREW TIMES
NO YES
Freq&AdjustCaps?
NO YES
125.0 0000 * MAIN
TEST RFID BOARD
NO YES
This screen will automatically scroll through all warmers.
Press right hidden button to advance to next function.
This allows you to monitor individual sensing coils and RFID board.
RFID CIRCUIT BOARD
VERSION # xx.xx
CONTINUED
39132.3 040312
