PROGRAM: F12 53
Label: A label of up to 7 characters can be entered for function keys in ASCII
emulations only. See “Display NV Labels” in the Emulation section.
< Backspace > – delete
< Shift > < Back > – default field
Key: Select the key to be programmed. The keys that are listed as choices depend upon
the Program parameter as shown below:
The following choices apply for non-SCO Console emulations:
When a PC-style keyboard is attached, the choices are:
When Program = F/Key , Sh-F/Key , Ctrl-FKey, or Ctrl-Sh-Fkey the choices are [F1,
F2, F3, F4, F5, F6, F7, F8 F9, F10, F11, F12].
When Program = Edit Key or Sh-Edit Key , the choices are
[Tab, Esc, Backspace, Delete, Return, Home, ↑ , ↓ , ← , → , EnterKpd, Insert,
PageDown, PageUp, End, and Print].
When an ANSI keyboard is attached, the choices are:
When Program = F/Key or Sh-F/ Key, the choices are [F1, F2, F3, F4, F5, F6, F7,
F8, F9, F10, F11, F12, F13, F14, Help, Do, F17, F18, F19, F20].
When Program = Edit Key or Sh-Edit key, the choices are
[Tab, ↑ , ↓ , ← , → , Enter, Next Screen, Remove, PF1, PF2,
PF3, PF4].
When Program = Edit Key or Sh-Edit Key, the choices are [Tab, Esc,
Backspace, Return, Print, Enter Kpd, ↑ , ↓ , ← , → , Insert, Delete, Home, BackTab,
Clear, and ErEOF.]
To program an ESC (escape) character into the key text, press Ctrl-[ .
To program a DEL character into the text field, press Ctrl-Sh-8 (alphanumeric key).
To program a carriage return or line feed into the key text field, press Ctrl-M or Ctrl-J ,
respectively.
To program the “Print Screen” key to perform a local print screen (page) function:
In the key text field, press
Ctrl-[ and then P . Next, set the “Key Dir”=Screen option.
