MIC input 1/4"
balanced TRS
Stereo
PHONES jack
REVERSE HOLD/TAP switch
inverts CROSSFADER for rapid
switching between sources.
Pressing switch down engages
effect until released. Flipping
switch up locks effect on
XFADE CURVE knob allows
user to custom-tailor
CROSSFADER response
Power switch
Stereo AMP MAIN
OUT RCA jacks
IEC Power socket
Stereo FX RETURN RCA
jacks from external FX
device to MAIN
Stereo FX SEND RCA
jacks from PFL bus to
external FX device
Channel 1 & 2 stereo PHONO/
LINE INPUTS with selection
switches and phono GND
(Ground) connectors
USB connection
socket
Channel 1 & 2 stereo PHONO/
LINE INPUTS with selection
switches and phono GND
(Ground) connectors
