LHM 280
5
Maximum crane capacity 64 t
Hook operation Capacity under 40´ spreader
Outreach
on the ropes
automatic semi-automatic
(m)
(t)
(t)
(t)
10
64.0
41.0
36.0
11
64.0
41.0
36.0
12
64.0
41.0
36.0
13
64.0
41.0
36.0
14
64.0
41.0
36.0
15
64.0
41.0
36.0
16
64.0
41.0
36.0
17
64.0
41.0
36.0
18
64.0
41.0
36.0
19
64.0
41.0
36.0
20
64.0
41.0
36.0
21
62.2
41.0
36.0
22
58.6
41.0
36.0
23
55.0
41.0
36.0
24
51.4
40.2
36.0
25
48.5
37.3
36.0
26
45.6
34.4
36.0
28
40.7
29.5
35.9
30
36.6
25.4
31.8
32
33.1
21.9
28.3
34
30.1
18.9
25.3
36
27.4
16.2
22.6
38
25.1
13.9
20.3
40
22.6
11.4
17.8
Container operation
Weight rotator 2.2 t
Weight fully automatic (telescopic) spreader 9 t
Weight semi-automatic spreader 1.3 t (20 ft), 2.6 t (40 ft)
Professional container handling – Turnover up to 35 cycles per hour
Precision to perfection: With incredibly short acceleration times for all crane motions, Liebherr is the top performer in
container handling.
• The crane can be fitted with various types of spreaders
(fixed or telescopic) connected to the rotator. Manual, semi
or fully automatic telescopic spreaders are available for
various container sizes.
• Liebherr Cycoptronic
®
is an accurate, sway-free load motion
control system that uses in-house designed software.
Cycoptronic
®
allows for direct load positioning and aids
the crane driver in mastering his task. With Cycoptronic
®
turnover, safety and the confidence of the operator will be
improved.
• Safety: The luffing cylinder is positioned above the lattice
boom. This eliminates the possibility of any damage to the
cylinder through swinging loads or highly stowed rows of
containers on board the vessel.
• The Liebherr hydrostatic drive is the most reliable and
highest performing drive system for mobile harbour
cranes. Independent closed loop hydraulic systems utilize
the minimum number of components to guarantee highly
responsive, smooth and precise operation while maximizing
operational safety.
Maximum crane capacity 84 t
Hook operation Capacity under 40´ spreader
Outreach
on the ropes
automatic semi-automatic
(m)
(t)
(t)
(t)
10
84.0
41.0
36.0
11
84.0
41.0
36.0
12
84.0
41.0
36.0
13
84.0
41.0
36.0
14
84.0
41.0
36.0
15
84.0
41.0
36.0
16
81.8
41.0
36.0
17
76.5
41.0
36.0
18
72.8
41.0
36.0
19
68.3
41.0
36.0
20
65.1
41.0
36.0
21
62.2
41.0
36.0
22
58.6
41.0
36.0
23
55.0
41.0
36.0
24
51.4
40.2
36.0
25
48.5
37.3
36.0
26
45.6
34.4
36.0
28
40.7
29.5
35.9
30
36.6
25.4
31.8
32
33.1
21.9
28.3
34
30.1
18.9
25.3
36
27.4
16.2
22.6
38
25.1
13.9
20.3
40
22.6
11.4
17.8
