LH 120 M Litronic Machine for Industrial Applications
3
Dimensions
H0289
D
E
H
K
L4
L3
L2
L1
U
V
X
W
A
A1
A2
Q1
C
Q
N
S
B
B1
H0290
9300
8500
800
3000
11500
8500
8050
5050
3000
800
10686
11486
without
Turret
Turret
turret
mm
1.20m
mm
2.00m
mm
A
4,814
4,814
4,814
A1
5,220
5,220
5,220
A2
6,115
6,115
6,115
B
5,500
5,500
5,500
B1
–
5,796
5,796
C
8,854
10,054
10,854
D
4,912
4,912
4,912
E
5,020
5,020
5,020
H
6,323
7,523
8,323
K
3,568
4,768
5,568
L1
2,100
2,100
2,100
L2
2,000
2,000
2,000
L3
2,000
2,000
2,000
L4
2,100
2,100
2,100
N
1,700
1,700
1,700
Q
1,431
1,431
1,431
Q1
406
406
406
S
3,800
3,800
3,800
U
11,137
11,137
11,137
E = Tail radius
without
Turret
Turret
turret
1.20m
2.00m
Industrial-TypeAngledMonoBoom15.00m
andIndustrialStick
m 12.00 13.50 12.00 13.50 12.00 13.50
V
mm 11,000 10,350 11,050 10,200 11,150 10,500
W
mm 7,950 9,800 8,700 9,950 9,250 10,450
X
mm 21,400 21,100 22,100 21,400 21,350 21,450
Industrial-TypeAngledMonoBoom13.50m
andIndustrialStick
m 10.50 12.00 10.50 12.00 10.50 12.00
V
mm 11,050 10,450 11,150 10,600 11,200 10,550
W
mm 7,750 9,250 8,600 9,800 9,100 10,100
X
mm 19,950 19,800 19,900 20,000 19,850 20,050
Industrial-TypeStraightMonoBoom13.50m
andIndustrialStick
m 10.50 12.00 10.50 12.00 10.50 12.00
V
mm 11,750 11,250 12,200 11,500 12,950 11,350
W
mm 7,000 8,750 7,900 9,000 8,700 9,000
X
mm 20,000 19,800 20,000 19,950 20,100 20,050
