Liebherr IK 2750 Premium - Manual (Page 6)

5.3.4 Fan*
With the fan you can rapidly cool large quantities of
fresh food or achieve a relatively even distribution of
temperature across all the storage levels.
The forced-air cooling is to be recommended:
- at high room temperature (above33 °C )
- at high humidity
The forced-air cooling uses slightly more energy. To save
energy, the fan switches off automatically when the door is
open.
Switching on the fan*
u
Briefly press the fan button Fig. 2 (5) .
w The fan symbol Fig. 2 (6) shines.
w The fan is active. In some appliances, the fan is only acti-
vated when the compressor is running.
To switch off the fan*
u
Briefly press the fan button Fig. 2 (5) .
w The fan symbol Fig. 2 (6) goes out.
w The fan is switched off.
5.3.5 Shelves
Relocating the shelves
The shelves have stops preventing them from being uninten-
tionally pulled out.
u Lift the shelf and draw it out
forwards.
u Insert shelf with the raised
edge pointing upwards at
the back.
w The food does not freeze
onto the rear wall.
Dismantling shelves
u
The shelves can be disman-
tled for cleaning.
5.3.6 Using the sectioned shelf
u Slide the sectioned shelf
under, as shown in the illus-
tration.
Fig. 3
u Attach the support rails, paying attention to the right (R) and
left (L) part!
u The glass shelf with stop face (2) has to be at the back.
u The glass plate (1) with pull-out stops must be at the front so
that the stops (3) face downwards.
5.3.7 Door racks
Moving the storage rack
Fig. 4
The boxes can be removed
and placed on the table as a
single unit.
Either one or both the boxes can be used. If particularly tall
bottles are to be stored, hang only a single box above the bottle
rack.
u Re-positioning the boxes:
Lift them for removal and re-
position them as required.
Dismantling door racks
Fig. 5
Control
6 * Depending on model and options
